NSN 5355-00-376-8722 210896, 21089-6, 00-376-8722
Product Details | SCALE DIAL
5355-00-376-8722 A dial designed to be read in conjunction with a vernier indicator, pointer(s) or like instruments, which device is not an integral part of the item. The item does not have facilities for connection to a tuning or selection mechanism to position the mechanism. However, it may be designed to be mounted on a knob used to position the mechanism. Excludes SCALEPLATE, ELECTRICAL METER. See also DIAL, CONTROL.
Part Alternates: 210896, 21089-6, 5355-00-376-8722, 00-376-8722, 5355003768722, 003768722
Hardware and Abrasives | Knobs and Pointers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-376-8722 | 03264 ( DIAL, SCALE ) |
Drawings & Photos | NSN 5355-00-376-8722
Cross Reference | NSN 5355-00-376-8722
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 21089-6 | 14418 | UNISYS CORP DEFENSE SYSTEMS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5355-00-376-8722
Technical Data | NSN 5355-00-376-8722
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY DIAL |
| STYLE DESIGNATOR | A92 ROUND |
| OUTSIDE DIAMETER | 4.000 INCHES NOMINAL |
| MOUNTING HOLE DIAMETER | 0.166 INCHES NOMINAL |
| MOUNTING HOLE QUANTITY | 3 |
| ATTACHMENT METHOD | HOLE |
| SCALE DIRECTION AND RANGE | 60 TO 240 LEFT TO RIGHT SINGLE SCALE |
| SCALE TYPE | NONLINEAR SINGLE SCALE |
| SCALE DIVISION QUANTITY | 36 SINGLE SCALE |
| SPECIAL FEATURES | 0.061 IN. THICKNESS OF MATERIAL; 0.750 IN. DIAMETER OF CENTER HOLE |
| (NON-CORE DATA) FSC APPLICATION DATA | USED ON SALINITY INDICATOR PANEL TYPE 12 |
| MANUFACTURERS CODE | 14418 |
| DESIGN CONTROL REFERENCE | 21089-6 |
Restrictions/Controls & Freight Information | NSN 5355-00-376-8722
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 095190 | HARDWARE, NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5355-00-376-8722
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | X | SEMIACTIVE ITEM-NO REPLACEMENT (NON-STOCKED ITEMS) A potentially inactive NSN which must be retained in the supply system as an item of supply because (1) stocks of the item are on hand or in use below the wholesale level and (2) the NSN is cited in equipment authorization documents TO & E, TA, TM, etc., or in-use assets are being reported. 1. Items are authorized for central procurement but not authorized for stockage at wholesale level. 2. Requisitions for in-use replacement will be authorized in accordance with individual Military Service directives. 3. Requisitions may be submitted as requirements generate. Repetitive demands may dictate an AAC change to permit wholesale stockage. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
