Product Details | SPACING THREADED STANDOFF
5340-01-102-2778 A standoff that must have a threaded end(s) or be internally threaded its full length. For items having external threads on both ends, see STUD (as modified). For items with an outside contour that is the same for the entire length, are flat on top and bottom, having internal threads its full length, and the length does not exceed twice the width across the flats or outside diameter, see NUT (as modified); use maximum dimensions(s) for compliance.
Part Alternates: 8209, 5340-01-102-2778, 01-102-2778, 5340011022778, 011022778
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 16 OCT 1980 | 01-102-2778 | 40280 ( STANDOFF, THREADED, SPACING ) |
Drawings & Photos | NSN 5340-01-102-2778
Demand History | NSN 5340-01-102-2778
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 8209 | 2014-10-302 | 12 | United States |
| 8209 | 2014-08-216 | 12 | United States |
| 8209 | 2014-05-140 | 108 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5340-01-102-2778
Related Products | NSN 5340-01-102-2778
Technical Data | NSN 5340-01-102-2778
| Characteristic | Specifications |
|---|---|
| CROSS-SECTIONAL SHAPE | ROUND |
| DIAMETER | 0.250 INCHES NOMINAL |
| STYLE DESIGNATOR | 6 LEFT INTERNAL AND RIGHT EXTERNAL THREAD |
| LENGTH | 1.375 INCHES NOMINAL |
| (NON-CORE DATA) EXTERNAL THREAD LENGTH | 0.188 INCHES NOMINAL |
| (NON-CORE DATA) FIRST INTERNAL THREAD LENGTH | 0.250 INCHES NOMINAL |
| (NON-CORE DATA) FIRST INTERNAL THREAD CHARACTERISTICS | 0.112-40 UNC-2B |
| (NON-CORE DATA) EXTERNAL THREAD CHARACTERISTICS | 0.172-40 UNC-2A |
| (NON-CORE DATA) MATERIAL | COPPER ALLOY |
| (NON-CORE DATA) SURFACE TREATMENT | NICKEL |
