NSN 5340-01-100-8138 C477017, C477-017, C4770173B
Product Details | FRICTION CATCH STUD RECEPTACLE
5340-01-100-8138 An item of resilient metallic material, or an item of resilient nonmetallic material which may be rigidly encased, having provisions for mounting to a door, panel, or the like. It is designed to receive and retain, by compression of the resilient material, a STUD, FRICTION CATCH, yet permit easy withdrawal of the stud under normal pull. For items of rigid material which mate with the plunger, bolt, ball, or the like, of a CATCH, FRICTION, see STRIKE, CATCH.
Part Alternates: C477017, C477-017, C4770173B, C477-017-3B, 12287808, 5340-01-100-8138, 01-100-8138, 5340011008138, 011008138
