NSN 5340-00-845-4961 5967, 00-845-4961, 008454961
Product Details | EXPANSION PLUG
5340-00-845-4961 A relatively thin metallic item, having a concave or cupped contour, designed to effect its own seal by compression against the circumference of a hole. It is used as a blowout plug in boilers, engines, and the like to relieve the pressure created by the expansion of fluids caused by heat or freezing.
Part Alternates: 5967, 5340-00-845-4961, 00-845-4961, 5340008454961, 008454961
Hardware and Abrasives | Hardware, Commercial
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
53 | 01 JAN 1963 | 00-845-4961 | 03797 ( PLUG, EXPANSION ) |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 5340-00-845-4961
Related Products | NSN 5340-00-845-4961
Technical Data | NSN 5340-00-845-4961
Characteristic | Specifications |
---|---|
MATERIAL | ALUMINUM |
SURFACE TREATMENT | ANODIZED |
STYLE DESIGNATOR | B4 CONCAVE |
RADIUS | 0.219 INCHES NOMINAL |
OUTSIDE DIAMETER | 0.250 INCHES NOMINAL |
MATERIAL THICKNESS | 0.032 INCHES NOMINAL |
SPECIAL FEATURES | 1/16 IN. DIA HOLE IN. CENTER |
MANUFACTURERS CODE | 13669 |
DESIGN CONTROL REFERENCE | 5967 |
Restrictions/Controls & Freight Information | NSN 5340-00-845-4961
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
Category | Code | Description |
---|---|---|
NMF Description | 013120 | ALUMINUM ARTICLE NOI SUB 6 |
Less than car load rating | ||
Less than truck load rating | J | 100.2 |
Water commodity Code | 713 | unknown |
Originating Activity Code | XX | |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5340-00-845-4961
Category | Code | Description |
---|---|---|
Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DF | Department of the Air Force |
Service Organization | F | U.S. Air Force |
Reparability | N | Stock Fund (except Munitions) |
Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
