Product Details | PAWL FASTENER
5340-00-780-4078 A self-contained item with a knob or a key actuated pawl, designed to fasten panels, doors, and the like, to frames or adjoining surfaces. The pawl may be preset to accommodate frames or surfaces of a specific thickness, or may be adjustable to accommodate frames or surfaces of variable thicknesses. For items with adjustable pawls, the pawl must be actuated through continual rotation of the knob or key until the pawl engages the adjoining surface.20311900057Specialized Test and Handling Equipment, Nuclear Ordnance53400020Hardware, Commercial
Part Alternates: 10179176-2, 62-10-201-30, 622023, 62-20-23, 5340-00-780-4078, 00-780-4078, 5340007804078, 101791762, 621020130, 007804078
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 15 MAR 1968 | 00-780-4078 | 28416 ( FASTENER, PAWL ) |
