NSN 5340-00-680-8998 FFS325, 00-680-8998, 006808998
Product Details | EXPANSION SHIELD
5340-00-680-8998 An item for inserting in a hole, usually in masonry, designed to be expanded either by means of a setting tool or by the insertion of the bolt, screw or nail for mounting or attaching another object. It may include the bolt, screw or nail.
Part Alternates: FFS325, 5340-00-680-8998, 00-680-8998, 5340006808998, 006808998
Hardware and Abrasives | Hardware, Commercial
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
53 | 01 JAN 1963 | 00-680-8998 | 08322 ( SHIELD, EXPANSION ) |
Cross Reference | NSN 5340-00-680-8998
Part Number | Cage Code | Manufacturer |
---|---|---|
FFS325 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 5340-00-680-8998
Related Products | NSN 5340-00-680-8998
Technical Data | NSN 5340-00-680-8998
Characteristic | Specifications |
---|---|
MATERIAL | ANY ACCEPTABLE |
SURFACE TREATMENT | ANY ACCEPTABLE |
STYLE DESIGNATOR | D6 MACHINE SCREW TYPE |
HOLE ACCOMMODATION DIAMETER | 0.500 INCHES NOMINAL |
INSERT TYPE FOR WHICH DESIGNED | MACHINE BOLT |
INSERT SIZE | 1/4/0.250 IN./-20 |
UNIT QUANTITY | 2 |
OVERALL LENGTH | ANY ACCEPTABLE |
THREAD PROVISION | THREADED |
CLOSED END | NOT INCLUDED |
SAFE OPERATING LOAD RATING | 168.7 POUNDS NOMINAL |
INSTALLATION SETTING TOOL | REQUIRED |
FASTENER TYPE | DUMMY STUD |
NOMINAL LENGTH | ANY ACCEPTABLE |
LEFT-HAND THREAD | NOT PROVIDED |
NONDEFINITIVE SPEC/STD DATA | 1 GROUP AND 1 TYPE AND 2 CLASS |
MANUFACTURERS CODE | 81348 |
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | FFS325 |
Restrictions/Controls & Freight Information | NSN 5340-00-680-8998
Category | Code | Description |
---|---|---|
Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Precious Metals Indicator Code: | U | Precious metal type is unknown |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
No Freight Information |
Management | NSN 5340-00-680-8998
Category | Code | Description |
---|---|---|
Materiel Category and Inventory Manager | T | Industrial Supplies (DLA/GSA Items) |
Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
Specific Group/Generic Code | 0 | Medical Materiel |
Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
Source of Supply | S9I | Defense Industrial Supply Center Philadelphia, PA 19111 |
Agency | DA | Department of the Army |
Service Organization | A | U.S. Army |
Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
