NSN 5330-01-045-2794 010452794
Product Details | WIPER RING
5330-01-045-2794 A circular, single or multipiece, rigid, metallic or nonmetallic item having a centrally located hole with a sharp edge on the inside periphery. It is supplied in various cross-sectional shapes and is designed to be installed in a cylinder, shock strut, or similar device to remove excess oil, dirt, ice, and/or foreign material from a piston, ram, or sliding rod. Excludes PACKING, PREFORMED; RING, PISTON; and SEAL RING, METAL.
Part Alternates: 010452794
Vehicular Equipment Components | Miscellaneous Vehicular Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 01-045-2794 | 20256 ( RING, WIPER ) |
Drawings & Photos | NSN 2590-01-045-2794
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5330-01-045-2794
Technical Data | NSN 5330-01-045-2794
| Characteristic | Specifications |
|---|---|
| MATERIAL | RUBBER SYNTHETIC OVERALL |
| CROSS-SECTIONAL SHAPE STYLE | B8 OUTSIDE GROOVED AND BEVELED, STRAIGHT FACE |
| RING STYLE | 7 CONCENTRIC |
| INSIDE DIAMETER | 1.000 INCHES NOMINAL |
| OUTSIDE DIAMETER | 1.262 INCHES NOMINAL |
| MATERIAL THICKNESS | 0.182 INCHES NOMINAL |
| OUTER EDGE THICKNESS | 0.105 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 5330-01-045-2794
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
