NSN 5325-00-780-7033 PL30103, PL301-0-3, 00-780-7033
Product Details | PUSH BUTTON FASTENER STUD
5325-00-780-7033 A metal fastening device having retractable engaging prong(s) or engaging rings actuated by a spring loaded button designed to mate with a SOCKET, PUSH BUTTON FASTENER. May include a clinch plate.
Part Alternates: PL30103, PL301-0-3, 5325-00-780-7033, 00-780-7033, 5325007807033, 007807033
Hardware and Abrasives | Fastening Devices
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 15 MAR 1968 | 00-780-7033 | 17969 ( STUD, PUSH BUTTON FASTENER ) |
Drawings & Photos | NSN 5325-00-780-7033
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5325-00-780-7033
Related Products | NSN 5325-00-780-7033
Technical Data | NSN 5325-00-780-7033
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| SURFACE TREATMENT | NICKEL EYELET CADMIUM OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-N-290 CLASS 2 FED SPEC SINGLE TREATMENT RESPONSE HEAD QQ-P-416 TYPE 2 CLASS 2 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| STUD RETENTION METHOD | RETAINING RING |
| PUSH BUTTON STUD STYLE | 10 STUD |
| BODY OUTSIDE DIAMETER | 0.437 INCHES NOMINAL |
| BODY FLANGE OUTSIDE DIAMETER | 0.552 INCHES MINIMUM AND 0.572 INCHES MAXIMUM |
| STUD BODY LENGTH | 0.480 INCHES MINIMUM AND 0.510 INCHES MAXIMUM |
| MANUFACTURERS CODE | 0HDW7 |
| DESIGN CONTROL REFERENCE | PL301-0-3 |
