NSN 5325-00-619-8485 V4109S, V4-109S, V4138
Product Details | TURNLOCK FASTENER RECEPTACLE
5325-00-619-8485 A threaded or tempered item used to secure the STUD, TURNLOCK FASTENER or STUD ASSEMBLY, TURNLOCK FASTENER by engaging with the cross pin, cam lead threads, or eared nut of the STUD, TURNLOCK FASTENER and securing it by means of its thread locking or spring action.
Part Alternates: V4109S, V4-109S, V4138, V4-138, 5325-00-619-8485, 00-619-8485, 5325006198485, 006198485
Hardware and Abrasives | Fastening Devices
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 28 JUN 1971 | 00-619-8485 | 18485 ( RECEPTACLE, TURNLOCK FASTENER ) |
Drawings & Photos | NSN 5325-00-619-8485
Demand History | NSN 5325-00-619-8485
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| V4-109S | 2024-10-291 | 306 | DIBBS |
| V4-109S | 2024-07-200 | 85 | DIBBS |
| V4-109S | 2024-06-178 | 618 | DIBBS |
| V4-109S | 2024-03-77 | 34 | DIBBS |
| V4-109S | 2023-12-351 | 310 | DIBBS |
| V4-109S | 2023-12-338 | 380 | DIBBS |
| V4-109S | 2023-09-260 | 380 | DIBBS |
| V4-109S | 2023-06-170 | 91 | DIBBS |
| V4-109S | 2023-03-75 | 115 | DIBBS |
| V4-109S | 2022-12-349 | 57 | DIBBS |
| V4-109S | 2022-06-173 | 218 | DIBBS |
| V4-109S | 2022-03-79 | 77 | DIBBS |
| V4-109S | 2022-02-40 | 187 | DIBBS |
| V4-109S | 2022-01-25 | 187 | DIBBS |
| V4-109S | 2021-11-322 | 16 | DIBBS |
| V4109S | 2021-09-258 | 4 | US |
| V4109S | 2021-07-196 | 14 | US |
| V4-109S | 2020-10-281 | 358 | DIBBS |
| V4-109S | 2020-01-05 | 93 | DIBBS |
| 5325-00-619-8485 | 2018-04-94 | 121 | DIBBS |
| 5325-00-619-8485 | 2012-06-181 | 1636 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5325-00-619-8485
Related Products | NSN 5325-00-619-8485
Technical Data | NSN 5325-00-619-8485
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| SURFACE TREATMENT | CADMIUM AND CHROMATE OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416,TY 2,CL 3 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| TURNLOCK RECEPTACLE STYLE | 28 FLOATING |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING HOLES | 0.875 INCHES NOMINAL |
| RECEPTACLE OVERALL LENGTH | 1.125 INCHES NOMINAL |
| RECEPTACLE HEIGHT | 0.625 INCHES NOMINAL |
| RECEPTACLE WIDTH | 0.625 INCHES NOMINAL |
| MOUNTING STYLE | 2 PLAIN W/MOUNTING HOLE |
| TURNLOCK MOUNTING HOLE DIAMETER | 0.098 INCHES MINIMUM AND 0.101 INCHES MAXIMUM |
| FEATURES PROVIDED | PROTECTIVE CAP |
| MANUFACTURERS CODE | 03024 |
| DESIGN CONTROL REFERENCE | V4-109S |
