NSN 5325-00-415-2088 CP0063L, CP006-3L, KNKL0632
Product Details | SCREW THREAD INSERT
5325-00-415-2088 A cylindrical item which may have wrenching and/or driving facilities and/or shoulders. It is designed to be inserted in a drilled, tapped or a pretapped hole, or molded or pressed into soft material to reduce the size of a tapped hole; to provide threads; to add strength, and/or to prevent stripping. It is one of the following: (1) a one-piece, flanged or unflanged, internally threaded item which may have external threads, and/or serrations around the periphery of the collar, designed to engage a serrated lock ring which is not included with the item; (2) a one-piece precision coiled wire; (3) a two-piece item consisting of an internally threaded cylinder and a mating externally threaded part; or (4) a one-piece internally threaded item whose outside diameter is tapered and/or knurled and/or with fin(s). The internal thread of the item may have a locking feature. Excludes items having a sleeve on on its under portion which can be clinched or crimped. Excludes BUSHING,MACHINE THREAD; NUT,PLAIN,KNURLED; NUT,PLAIN,ROUND; NUT,PLAIN,CLINCH and NUT,SELF-LOCKING,CLINCH. See also NUT,PLAIN,PLATE
Part Alternates: CP0063L, CP006-3L, KNKL0632, KNKL0632J, KNKL0632S, 6005901803, 60-059018-03, 60945641, 6094564-1, 642AS07144, 642AS0714-4, 64AS07144, 64AS0714-4, 704AS93266, 704AS9326-6, 8993266, 899326-6, 9352752, 935275-2, 5325-00-415-2088, 00-415-2088, 5325004152088, 004152088
Hardware and Abrasives | Fastening Devices
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 20 NOV 1970 | 00-415-2088 | 11444 ( INSERT, SCREW THREAD ) |
Drawings & Photos | NSN 5325-00-415-2088
Demand History | NSN 5325-00-415-2088
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| KNKL0632J | 2024-04-93 | 1100 | United States |
| KNKL0632J | 2023-12-354 | 132 | us |
| 5325-00-415-2088 | 2018-08-231 | 200 | IL |
| KNKL0632J | 2014-05-127 | 15 | US |
| 5325-00-415-2088 | 2013-10-298 | 200 | US |
| 642AS07144 | 2013-05-122 | 287 | United Kingdom |
| 642AS07144 | 2013-05-122 | 287 | UK |
| 5325-00-415-2088 | 2013-04-95 | 60 | United States |
| 5325-00-415-2088 | 2013-03-70 | 16 | United States |
| 5325-00-415-2088 | 2013-02-58 | 236 | United States |
| 5325-00-415-2088 | 2012-06-173 | 96 | United States |
| 5325-00-415-2088 | 2012-06-166 | 48 | United States |
| KNKL0632J | 2011-05-138 | 30 | us |
| KNKL0632J | 2011-01-17 | 300 | US |
| 5325-00-415-2088 | 2007-10-295 | 122 | US |
Cross Reference | NSN 5325-00-415-2088
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 60-059018-03 | 15280 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV ES DEFENSIVE SYSTEMS DIVISION |
| 60-059018-03 | 26916 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV MULTIPLE |
| 6094564-1 | 03640 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 642AS0714-4 | 30003 | NAVAL AIR SYSTEMS COMMAND |
| 64AS0714-4 | D9182 | BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT |
| 704AS9326-6 | 30003 | NAVAL AIR SYSTEMS COMMAND |
| 899326-6 | D9182 | BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT |
| 935275-2 | 82577 | RAYTHEON COMPANY DBA RAYTHEON |
| CP006-3L | D9182 | BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT |
| KNKL0632 | 17446 | HUCK INTERNATIONAL, INC. DBA ALCOA FASTENING SYSTEMS |
| KNKL0632 | 29372 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| KNKL0632 | 97928 | HUCK INTL INC |
| KNKL0632J | 29372 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| KNKL0632S | 29372 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
