NSN 5325-01-119-3206 MA3279202, MA3279-202, TNM-3X.5C-6
Product Details | SCREW THREAD INSERT
5325-01-119-3206 A cylindrical item which may have wrenching and/or driving facilities and/or shoulders. It is designed to be inserted in a drilled, tapped or a pretapped hole, or molded or pressed into soft material to reduce the size of a tapped hole; to provide threads; to add strength, and/or to prevent stripping. It is one of the following: (1) a one-piece, flanged or unflanged, internally threaded item which may have external threads, and/or serrations around the periphery of the collar, designed to engage a serrated lock ring which is not included with the item; (2) a one-piece precision coiled wire; (3) a two-piece item consisting of an internally threaded cylinder and a mating externally threaded part; or (4) a one-piece internally threaded item whose outside diameter is tapered and/or knurled and/or with fin(s). The internal thread of the item may have a locking feature. Excludes items having a sleeve on on its under portion which can be clinched or crimped. Excludes BUSHING,MACHINE THREAD; NUT,PLAIN,KNURLED; NUT,PLAIN,ROUND; NUT,PLAIN,CLINCH and NUT,SELF-LOCKING,CLINCH. See also NUT,PLAIN,PLATE
Part Alternates: MA3279202, MA3279-202, TNM-3X.5C-6, TNM3X5C6, 55179001203, 5517900-1203, 10843CN060, 1084-3CN060, 1084-3CN6.0, 10843CN60, 13029171-1, 5325-01-119-3206, 01-119-3206, 5325011193206, 011193206, 130291711
Hardware and Abrasives | Fastening Devices
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 22 SEP 1981 | 01-119-3206 | 11444 ( INSERT, SCREW THREAD ) |
Drawings & Photos | NSN 5325-01-119-3206
