NSN 5325-00-085-4484 SR086, 1094961, 109496-1
Product Details | SCREW THREAD INSERT
5325-00-085-4484 A cylindrical item which may have wrenching and/or driving facilities and/or shoulders. It is designed to be inserted in a drilled, tapped or a pretapped hole, or molded or pressed into soft material to reduce the size of a tapped hole; to provide threads; to add strength, and/or to prevent stripping. It is one of the following: (1) a one-piece, flanged or unflanged, internally threaded item which may have external threads, and/or serrations around the periphery of the collar, designed to engage a serrated lock ring which is not included with the item; (2) a one-piece precision coiled wire; (3) a two-piece item consisting of an internally threaded cylinder and a mating externally threaded part; or (4) a one-piece internally threaded item whose outside diameter is tapered and/or knurled and/or with fin(s). The internal thread of the item may have a locking feature. Excludes items having a sleeve on on its under portion which can be clinched or crimped. Excludes BUSHING,MACHINE THREAD; NUT,PLAIN,KNURLED; NUT,PLAIN,ROUND; NUT,PLAIN,CLINCH and NUT,SELF-LOCKING,CLINCH. See also NUT,PLAIN,PLATE
Part Alternates: SR086, 1094961, 109496-1, 41725701, 417257-01, 540725101C, 540725-101C, 616214, 61621-4, 71187951, 7118795-1, 9352701, 935270-1, 5325-00-085-4484, 00-085-4484, 5325000854484, 000854484
Hardware and Abrasives | Fastening Devices
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-085-4484 | 11444 ( INSERT, SCREW THREAD ) |
Drawings & Photos | NSN 5325-00-085-4484
Demand History | NSN 5325-00-085-4484
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5325-00-085-4484 | 2016-02-42 | 186 | United States |
| 5325-00-085-4484 | 2015-12-355 | 186 | DIBBS |
Cross Reference | NSN 5325-00-085-4484
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 109496-1 | 37695 | RAYTHEON COMPANY DBA RAYTHEON |
| 417257-01 | 07690 | BAE SYSTEMS CONTROLS INC |
| 540725-101C | A0069 | SELEX ES SPA |
| 540725-101C | A2608 | BASTOGI SISTEMI SPA |
| 61621-4 | 22915 | NORTHROP GRUMMAN CORP ELECTRONIC SYSTEMS DEFENSIVE SYSTEM |
| 7118795-1 | 06481 | NORTHROP GRUMMAN SYSTEMS CORPORATION |
| 7118795-1 | 17863 | LITTON SYSTEMS INC GUIDANCE AND CONTROL SYSTEMS DIV |
| 935270-1 | 82577 | RAYTHEON COMPANY DBA RAYTHEON |
| SR086 | 83324 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
