Product Details | PLAIN TAPERED PIN
5315-00-198-5981 A cone-shaped, unthreaded, metallic or nonmetallic item, tapered through its entire length, primarily used to position and hold two or more mating parts in alignment.
Part Alternates: MS24692283, MS24692-283, AN385414, AN385-4-14, S21X25, 6573, 86513, 103607, 4566A, 5315-00-198-5981, 00-198-5981, 5315001985981, 001985981
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1961 | 00-198-5981 | 02391 ( PIN, TAPERED, PLAIN ) |
Drawings & Photos | NSN 5315-00-198-5981
Demand History | NSN 5315-00-198-5981
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5315-00-198-5981 | 2022-04-101 | 26 | DIBBS |
| 5315-00-198-5981 | 2022-03-89 | 26 | DIBBS |
| 5315-00-198-5981 | 2020-04-111 | 5 | DIBBS |
| MS24692-283 | 2013-08-229 | 176 | Canada |
| 5315-00-198-5981 | 2009-02-51 | 5 | DIBBS |
| 5315-00-198-5981 | 2009-01-22 | 5 | DIBBS |
Cross Reference | NSN 5315-00-198-5981
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 103607 | 12204 | DAIMLER CHRYSLER |
| 103607 | 24617 | GENERAL MOTORS CORP |
| 103607 | 7X677 | GENERAL MOTORS LLC DBA GENERAL MOTORS |
| 4566A | 1ML14 | D.W. HERCULES, LLC DBA HERCULES ENGINE COMPONENTS |
| 4566A | 28265 | HERCULES ENGINE CO INC |
| 4566A | 72260 | CORBITT CO INC |
| 6573 | 34623 | AM GENERAL, LLC |
| 86513 | 08683 | BROCKWAY MOTOR TRUCKS DIV OF MACK TRUCKS INC |
| AN385-4-14 | 81352 | AIR FORCE-NAVY AERONAUTICAL SPECIFICATIONS |
| AN385-4-14 | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
| MS24692-283 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| MS24692-283 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| S21X25 | 65282 | WHITE MOTOR CORP |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5315-00-198-5981
Related Products | NSN 5315-00-198-5981
Technical Data | NSN 5315-00-198-5981
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | 66 FED STD SINGLE MATERIAL RESPONSE OVERALL |
| FIRST END STYLE | 3 OVAL |
| FIRST END OUTER RADIUS | 0.490 INCHES MINIMUM AND 0.510 INCHES MAXIMUM |
| SECOND END RELATIONSHIP WITH FIRST END | IDENTICAL |
| FIRST END LOCATION | BOTH ENDS |
| SURFACE FINISH | 63.0 MICROINCHES SHANK END |
| PIN OVERALL LENGTH | 1.720 INCHES MINIMUM AND 1.780 INCHES MAXIMUM |
| PIN SIZE DESIGNATION | 4 |
