NSN 5310-01-600-5062 SPSN16915, SPS-N-16915, 59FAF518
Product Details | HEX CASTELLATED SELF-LOCKING NUT
5310-01-600-5062 A nut having 6 flat sides, flat on the bottom and having a slotted cylindrical or dome shaped upper portion. An integral feature is incorporated for locking on the threads of a mating member. The slots when used in conjunction with a solid or split (cotter) pin, act as an extra "fail safe" feature in critical applications. Excludes NUT (1), SELF-LOCKING, SLOTTED, HEXAGON.
Part Alternates: SPSN16915, SPS-N-16915, 59FAF518, 59FAF-518 , 59FC1032, 59FC-1032, 5310-01-600-5062, 01-600-5062, 5310016005062, 016005062
Hardware and Abrasives | Nuts and Washers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 06 DEC 2011 | 01-600-5062 | 29725 ( NUT, SELF-LOCKING, CASTELLATED, HEXAGON ) |
Demand History | NSN 5310-01-600-5062
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 59FC1032 | 2009-06-161 | 100 | Canada |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5310-01-600-5062
Technical Data | NSN 5310-01-600-5062
| Characteristic | Specifications |
|---|---|
| THREAD DIRECTION | RIGHT-HAND |
| PART NAME ASSIGNED BY CONTROLLING AGENCY | NUT, FLEXLOC, LIGHT HEX SERIES, SELF-LOCKING |
| NOMINAL THREAD SIZE | 0.190 INCHES |
| SURFACE TREATMENT | SILVER OVERALL |
| THREAD QUANTITY PER INCH | 32 |
| LOCKING FEATURE | PREVAILING TORQUE ALL METAL DESIGN |
| THREAD SERIES | UNJF |
| WIDTH ACROSS FLATS | 0.367 INCHES MINIMUM AND 0.376 INCHES MAXIMUM |
| NUT STYLE | CASTELLATED, HEXAGON |
| NUT HEIGHT | 0.243 INCHES NOMINAL |
| END ITEM IDENTIFICATION | TYPE 45 DESTROYER |
| MATERIAL | STEEL COMP 301 OVERALL OR STEEL COMP 302 OVERALL OR STEEL COMP 303 OVERALL OR STEEL COMP 304 OVERALL |
| BEARING SURFACE TYPE | CHAMFERED |
| THREAD CLASS | 3B |
Restrictions/Controls & Freight Information | NSN 5310-01-600-5062
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | S | Item contains silver |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
