NSN 5310-01-445-9269 AS306811, AS3068-11, 01-445-9269
Product Details | DOUBLE HEXAGON SELF-LOCKING NUT
5310-01-445-9269 A nut having 12 drive points and 24 sides. The bearing surface may be washer faced. An integral locking feature is incorporated in the design of the head or in the threads.
Part Alternates: AS306811, AS3068-11, 5310-01-445-9269, 01-445-9269, 5310014459269, 014459269
Hardware and Abrasives | Nuts and Washers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 17 JUN 1997 | 01-445-9269 | 05276 ( NUT, SELF-LOCKING, DOUBLE HEXAGON ) |
Demand History | NSN 5310-01-445-9269
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5310-01-445-9269 | 2008-11-310 | 100 | US |
| AS306811 | 2008-10-282 | 100 | United Kingdom |
Cross Reference | NSN 5310-01-445-9269
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| AS3068-11 | 73342 | ALLISON TRANSMISSION, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5310-01-445-9269
Technical Data | NSN 5310-01-445-9269
| Characteristic | Specifications |
|---|---|
| THREAD SERIES | UNJF |
| NOMINAL THREAD SIZE | 0.312 INCHES |
| THREAD QUANTITY PER INCH | 24 |
| THREAD CLASS | 3B |
| THREAD DIRECTION | RIGHT-HAND |
| MATERIAL | IRON ALLOY 660 OVERALL |
| HARDNESS RATING | 38.0 ROCKWELL C MINIMUM AND 45.0 ROCKWELL C MAXIMUM |
Restrictions/Controls & Freight Information | NSN 5310-01-445-9269
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
