NSN 5310-00-124-9785 2094194, 209419-4, 00-124-9785
Product Details | KEYWAY WASHER
5310-00-124-9785 A washer of nonresilient material usually having two parallel bearing surfaces. The outside and/or inside edges have one or more notches. Excludes thrust type washers.
Part Alternates: 2094194, 209419-4, 5310-00-124-9785, 00-124-9785, 5310001249785, 001249785
Hardware and Abrasives | Nuts and Washers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 18 NOV 1968 | 00-124-9785 | 06158 ( WASHER, KEYWAY ) |
Cross Reference | NSN 5310-00-124-9785
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 209419-4 | 59875 | EATON INDUSTRIAL CORPORATION DBA ARGO-TECH |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5310-00-124-9785
Related Products | NSN 5310-00-124-9785
Technical Data | NSN 5310-00-124-9785
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY 1100 OVERALL |
| INTERNAL KEYWAY QUANTITY | 1 |
| HOLE DIAMETER | 0.439 INCHES MINIMUM AND 0.444 INCHES MAXIMUM |
| OUTSIDE DIAMETER | 1.110 INCHES MINIMUM AND 1.130 INCHES MAXIMUM |
| INTERNAL KEYWAY WIDTH | 0.064 INCHES MINIMUM AND 0.070 INCHES MAXIMUM |
| DISTANCE FROM CENTERLINE TO BOTTOM OF INTERNAL KEYWAY | 0.043 INCHES MINIMUM AND 0.053 INCHES MAXIMUM |
| MATERIAL THICKNESS | 0.0067 INCHES MINIMUM AND 0.0073 INCHES MAXIMUM |
| III HEAT TREATMENT | F-AS FABRICATED |
| MANUFACTURERS CODE | 59875 |
| DESIGN CONTROL REFERENCE | 209419-4 |
Restrictions/Controls & Freight Information | NSN 5310-00-124-9785
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 194160 | WASHER OR GASKETS, IRON OR STEEL, |
| Less than car load rating | ||
| Less than truck load rating | U | 50.0 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | GX | HQ Defense Logistics Agency, Enterprise Business Systems Fort Belvoir, VA 22060 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5310-00-124-9785
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
