NSN 5307-01-024-7147 GS23D8, 01-024-7147, 010247147
Product Details | BONDED STUD
5307-01-024-7147 A headed fastener, externally threaded. The head is intended to be fastened by an adhesive. The head may also be fastened with rivets. The head is not designed to be turned with a wrench or inserted driver.
Part Alternates: GS23D8, 5307-01-024-7147, 01-024-7147, 5307010247147, 010247147
Hardware and Abrasives | Studs
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 19 JUL 1976 | 01-024-7147 | 37234 ( STUD, BONDED ) |
Drawings & Photos | NSN 5307-01-024-7147
Demand History | NSN 5307-01-024-7147
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5307-01-024-7147 | 2011-02-49 | 12 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5307-01-024-7147
Related Products | NSN 5307-01-024-7147
Technical Data | NSN 5307-01-024-7147
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | STUD STEEL COMP 1015,CADMIUM PLATED QQ-P-416 TYPE 1 CLASS 3.0.190-32 UNF 2A THREAD, 0.460 IN. LONG, BASE ALUMINUM ALLOY QQ-A-250/11 ALLOY 6061-T6, ANODIZED MIL-A-8625 TYPE 2 CLASS 1.0.040 IN. THICK, 1.250 IN. DIA, 5 HOLES 0.169 IN. MIN 0.174 IN. MAX DIA EQUALLY SPACED ON 0.875 IN. BOLT CIRCLE DIA |
| MANUFACTURERS CODE | 26512 |
| DESIGN CONTROL REFERENCE | GS23D8 |
Restrictions/Controls & Freight Information | NSN 5307-01-024-7147
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 093486 | BOLTS,NUTS OR SCREWS, NOI (SUB 3) |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 573 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
