Product Details | PROFILE GAGE

5220-01-011-1293 A gage used to check or inspect contour, radius, chamfer, depth, thickness and/or height by inclusive fit of a work piece.

Part Alternates: MCG5307, MCG5310, A1020, 5220-01-011-1293, 01-011-1293, 5220010111293, 010111293

Measuring Tools | Inspection Gages and Precision Layout Tools

Supply Group (FSG) NSN Assign. NIIN
52 15 OCT 1975 01-011-1293

Drawings & Photos | NSN 5220-01-011-1293


Demand History | NSN 5220-01-011-1293

Part Number Request Date QTY Origin
A1020 2023-03-69 60 US
A1020 2022-05-146 200 United States
A1020 2022-03-73 200 United States
A1020 2019-03-78 40 PL
A1020 2019-03-78 40 PL
A1020 2017-10-297 50 United Arab Emirates
A1020 2016-07-210 50 US
A1020 2015-08-217 100 US
A1020 2012-11-310 15 Indonesia
A1020 2011-03-84 500
A1020 2011-03-74 650
A1020 2010-11-322 200

Cross Reference | NSN 5220-01-011-1293

Part Number Cage Code Manufacturer
A1020 08080 KEMP/REAL-TIME LABORATORIES
MCG5307 62983 EATON AEROSPACE LLC
MCG5307 76050 EATON AEROSPACE LLC M C AEROSPACE DIV
MCG5310 76050 EATON AEROSPACE LLC M C AEROSPACE DIV

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5220-01-011-1293

Technical Data | NSN 5220-01-011-1293

Characteristic Specifications
DESIGN TYPE DOUBLE END
GAGE TYPE COMBINATION GO NOT GO
AIR GROOVE FEATURE NOT INCLUDED
SPECIAL FEATURES GAGE,AIR RING,GO;USED ON GUN SYSTEM GAU-8/A

Restrictions/Controls & Freight Information | NSN 5220-01-011-1293

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 121570 GAGES AIR LIQUID LEVEL PRESSURE
Less than car load rating J 100.2
Less than truck load rating J 100.2
Water commodity Code 657 unknown
Originating Activity Code TG Warner-Robins Air Logistics Center
Robins AFB, GA 31098-5609
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code Z unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable
