NSN 5210-01-193-6449 CM146, 01-193-6449, 011936449
Product Details | MICROMETER DEPTH GAGE
5210-01-193-6449 A precision instrument designed for accurately measuring the depth of grooves, holes, or irregular parts. It consists of a micrometer attached vertically to a base and one or more measuring rods.
Part Alternates: CM146, 5210-01-193-6449, 01-193-6449, 5210011936449, 011936449
Measuring Tools | Measuring Tools, Craftsmen's
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 52 | 06 NOV 1984 | 01-193-6449 | 15281 ( GAGE, DEPTH, MICROMETER ) |
Cross Reference | NSN 5210-01-193-6449
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| CM146 | 55719 | IDSC HOLDINGS LLC DBA SNAP-ON INDUSTRIAL |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5210-01-193-6449
Technical Data | NSN 5210-01-193-6449
| Characteristic | Specifications |
|---|---|
| DESIGN TYPE | MULTIPLE ROD |
| ROD QUANTITY | 6 |
| ROD SIZE DESIGNATION | 0.125 DIA |
| GAGING RANGE | 0.000 TO 6.000 INCHES |
| BASE LENGTH | 4.000 INCHES NOMINAL |
| GRADUATION UNIT | 0.0010 INCHES |
| RATCHET STOP | NOT INCLUDED |
| CASE | PROVIDED |
Restrictions/Controls & Freight Information | NSN 5210-01-193-6449
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
