NSN 4920-01-505-2201 A05G05065, A05G0506-5, 01-505-2201
Product Details | STORES MANAGEMENT SUBSYSTEM TEST SET
4920-01-505-2201 An item specifically designed for providing the necessary shop testing of the stores release equipment of an aircraft, such as air-to-ground pylons, launchers, adapters and bomb racks. Differs from TEST SET, STORES MANAGEMENT SYSTEM, in that it does not test the entire system, but the shop replaceable subsystems of the stores management system.
Part Alternates: A05G05065, A05G0506-5, 4920-01-505-2201, 01-505-2201, 4920015052201, 015052201
Maintenance and Repair Shop Equipment | Aircraft Maintenance and Repair Shop Specialized Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 49 | 26 FEB 2003 | 01-505-2201 | 39258 ( TEST SET, STORES MANAGEMENT SUBSYSTEM ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4920-01-505-2201
Technical Data | NSN 4920-01-505-2201
| Characteristic | Specifications |
|---|---|
| END ITEM IDENTIFICATION | F-15A/B/C/D MSIP |
| JOINT ELECTRONICS TYPE DESIGNATION SYSTEM ITEM NAME | GUIDED MISSILE LAUNCHER PYLON TEST SET |
| JOINT ELECTRONICS TYPE DESIGNATION SYSTEM ITEM TYPE NUMBER | A/E24T-170 |
| SPECIAL FEATURES | ONE COMBINATION CASE,18.0 X 18.0 X 20.0 INCHES;TWO TRANSIT CASES 22.5 X22.5 X 18.5 INCHES;COLOR:GREEN |
| III FUNCTIONAL DESCRIPTION | USED IN THE WPNS RELEASE SHOP TO PERFORM ELEC CONTINUITY AND FAULT ISOLATION CHECKS OF THE MISSILE LAUNCHERS AND ADAPTERS AND THE INBOARD/CENTERLINE AND MAU-12 BOMB RACKS |
| III REFERENCE DATA AND LITERATURE | SERD 9703(I);CCP 614;CP15A2023 |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | ARMAMENT TESTER |
| MANUFACTURERS CODE | 76301 |
| DESIGN CONTROL REFERENCE | A05G0506-5 |
Restrictions/Controls & Freight Information | NSN 4920-01-505-2201
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Controlled Inventory Item Code: | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
