NSN 4920-01-382-2767 M81714/67-02 , M817146702, AS81714/67
Product Details | STORES MANAGEMENT SUBSYSTEM TEST SET
4920-01-382-2767 An item specifically designed for providing the necessary shop testing of the stores release equipment of an aircraft, such as air-to-ground pylons, launchers, adapters and bomb racks. Differs from TEST SET, STORES MANAGEMENT SYSTEM, in that it does not test the entire system, but the shop replaceable subsystems of the stores management system.
Part Alternates: M81714/67-02 , M817146702, AS81714/67 , AS8171467, MIL-T-81714/67 , MILT8171467, W1040677, W104067-7, 918509 , 4920-01-382-2767, 01-382-2767, 4920013822767, 013822767
Maintenance and Repair Shop Equipment | Aircraft Maintenance and Repair Shop Specialized Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 49 | 29 OCT 1993 | 01-382-2767 | 39258 ( TEST SET, STORES MANAGEMENT SUBSYSTEM ) |
Drawings & Photos | NSN 4920-01-382-2767
Demand History | NSN 4920-01-382-2767
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| M817146702 | 2023-08-241 | 96 | US |
| M817146702 | 2022-07-195 | 65 | United States |
Cross Reference | NSN 4920-01-382-2767
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| W104067-7 | 91145 | FLEET READINESS CENTER SOUTHWEST |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4920-01-382-2767
Related Products | NSN 4920-01-382-2767
Technical Data | NSN 4920-01-382-2767
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | TEST SET CAN BE SERVICED TO HOLD INTERNAL PRESSURE UP TO 1,800 PSI OF NITROGEN. TEST SET CONSISTS OF SELF TEEST BOX, BREECH ADAPTERS, HOSE ASSEMBLY, AND CABLE ASSEMBLIES |
| MANUFACTURERS CODE | 91145 |
| DESIGN CONTROL REFERENCE | W104067-7 |
Restrictions/Controls & Freight Information | NSN 4920-01-382-2767
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | KE | Naval ICP Philadelphia, PA 19111 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | 3 | Electrostatic Sensitive Device (ESD), subject to damage caused by electrostatic discharge. (See DoD 4500.32-R, Volume 1, Appendix A, Section I for additional information on ESD devices). |
| NMF Description | 063160 | SWITCH BOXES/ELEC ENCLOSURES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | ZC | Canada ZD ZE |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
