NSN 4920-00-165-6989 CD32A153859, CD32A1538-59, 68D3200241001
Product Details | AIRCRAFT CONTROL RIGGING TEMPLATE
4920-00-165-6989 A device made of metal and/or plastic used for the aligment of controls and/or components of an aircraft control system and/or aircraft engine. It may have a graduated scale for measurement and/or holes for the insertion of rigging pins.
