NSN 4920-01-419-0427 T103225119, T103225-119, 01-419-0427
Product Details | AIRCRAFT CONTROL RIGGING TEMPLATE
4920-01-419-0427 A device made of metal and/or plastic used for the aligment of controls and/or components of an aircraft control system and/or aircraft engine. It may have a graduated scale for measurement and/or holes for the insertion of rigging pins.
Part Alternates: T103225119, T103225-119, 4920-01-419-0427, 01-419-0427, 4920014190427, 014190427
Maintenance and Repair Shop Equipment | Aircraft Maintenance and Repair Shop Specialized Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 49 | 12 SEP 1995 | 01-419-0427 | 45568 ( TEMPLATE, CONTROL RIGGING, AIRCRAFT ) |
Drawings & Photos | NSN 4920-01-419-0427
Demand History | NSN 4920-01-419-0427
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| T103225-119 | 2022-08-14 | 7 | DIBBS |
| 4920-01-419-0427 | 2022-03-24 | 1 | US |
| 4920-01-419-0427 | 2019-04-30 | 1 | United States |
| T103225119 | 2016-02-11 | 1 | Thailand |
| 4920-01-419-0427 | 2014-09-23 | 1 | Canada |
| T103225119 | 2012-05-31 | 1 | CO |
| T103225119 | 2011-08-08 | 1 | United States |
| 4920-01-419-0427 | 2009-02-24 | 2 | US |
Cross Reference | NSN 4920-01-419-0427
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| T103225-119 | 97499 | BELL HELICOPTER TEXTRON INC. |
