NSN 4820-01-420-4120 FK30702GB526630, 526630 DN100, 526630 DN125
Product Details | STOP-CHECK VALVE
4820-01-420-4120 A valve with a bolt or stem that may be mechanically actuated to two different positions by rotary or linear motion. In the first position, the valve disk is located and locked against the seat permitting no fluid flow through the valve. In the second position, one side of the valve disk is located against the seat permitting movement of the disk in a manner that will allow a flow of fluid in one direction through the valve. The valve disk may be spring loaded. It may be inline or cartridge (manifold) design. See also VALVE (1), LIFT-CHECK and VALVE (1), STOP-LIFT-CHECK.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: FK30702GB526630, 526630 DN100, 526630 DN125, 5266300100, 526630-0100 , 526630DN100, 526630DN125, 4820-01-420-4120, 01-420-4120, 4820014204120, 014204120
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 16 OCT 1995 | 01-420-4120 | 05486 ( VALVE, STOP-CHECK ) |
Drawings & Photos | NSN 4820-01-420-4120
Demand History | NSN 4820-01-420-4120
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4820-01-420-4120 | 2015-06-158 | 2 | DIBBS |
| 4820-01-420-4120 | 2015-03-68 | 2 | DIBBS |
| 4820-01-420-4120 | 2015-02-57 | 2 | DIBBS |
| 4820-01-420-4120 | 2014-10-303 | 2 | DIBBS |
| 4820-01-420-4120 | 2014-10-302 | 2 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4820-01-420-4120
Technical Data | NSN 4820-01-420-4120
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL BODY |
| STYLE DESIGNATOR | A9 STRAIGHT THRU DROP-IN CARTRIDGE |
| FLOW CONTROL DEVICE | DISK |
| MAXIMUM OPERATING PRESSURE | 100.0 POUNDS PER SQUARE INCH SINGLE RESPONSE |
| VALVE OPERATION METHOD | AUTOMATIC |
| CONNECTION TYPE | UNTHREADED CARTRIDGE ALL ENDS |
| CONNECTION STYLE | B61C GROOVED ALL ENDS |
| MOUNTING POSITION | HORIZONTAL |
| BONNET TYPE | INSIDE SPRING |
| BONNET ATTACHMENT METHOD | INTEGRAL |
| DISK LOADING METHOD | SPRING |
| SPECIAL FEATURES | AUXILIARY SPRING; STAINLESS DISK |
| END ITEM IDENTIFICATION | STRATEGIC SEALIFT CONVERSION SHIPS CLASS |
Restrictions/Controls & Freight Information | NSN 4820-01-420-4120
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051080 | FAUCETS,BIBCOCKS,GATES VALVES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4820-01-420-4120
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
