Product Details | FLANGE TO BOSS ELBOW
4730-01-171-2373 A fitting that forms an angle of less than 180 degrees (3.141 radians) from the straight flow. It has a flange connection on one end designed to connect with another flange connection, or a compression type mounting pad. The other end has external and/or internal machine threads (straight threads other than pipe or hose series), and is designed to facilitate a gasket, preformed packing, washer, or the like, to form a seal at the boss. It may have side and/or heel inlet(s).
Part Alternates: 10936985, 4730-01-171-2373, 01-171-2373, 4730011712373, 011712373
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 04 FEB 1984 | 01-171-2373 | 29665 ( ELBOW, FLANGE TO BOSS ) |
Cross Reference | NSN 4730-01-171-2373
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10936985 | 19207 | U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-01-171-2373
Technical Data | NSN 4730-01-171-2373
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY 6061 AND ALUMINUM ALLOY 6063 OVERALL |
| CONNECTION TYPE | FLANGE 1ST END UNTHREADED EXTERNAL TUBE 2ND END |
| CONNECTION STYLE | B101A GROOVED 2ND END |
| FLANGE SHAPE | ROUND WITH HOLES 1ST END |
| NOMINAL OUTSIDE DIAMETER | 7.500 INCHES 1ST END |
| NOMINAL THICKNESS | 0.500 INCHES 1ST END |
| BOLT HOLE QUANTITY | 4 1ST END |
| BOLT HOLE NOMINAL DIAMETER | 0.750 INCHES 1ST END |
| BOLT CIRCLE NOMINAL DIAMETER | 6.000 INCHES 1ST END |
| FLANGE FACE DESIGN | PLAIN 1ST END |
| NOMINAL OUTSIDE DIAMETER TUBE ACCOMMODATED | 3.500 INCHES 2ND END |
| TUBING WALL NOMINAL THICKNESS FOR WHICH DESIGNED | 0.120 INCHES 2ND END |
Restrictions/Controls & Freight Information | NSN 4730-01-171-2373
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 052190 | PIPE,TUBING,OR PIPE OR TUBING FITTI |
| Less than car load rating | U | 50 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | AZ | U.S. Army Tank-Automotive and Armaments Command Warren, MI 48397-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
