NSN 4730-01-141-9665 AN83230, AN832-30, 7M637
Product Details | TUBE NIPPLE
4730-01-141-9665 A straight, one-piece fitting used to join a tube or tube fitting to another tube or tube fitting. It may have any type externally threaded tube connections of the same size on both ends and is usually shaped externally at the center to accommodate a wrench. It may include nuts, sleeves, and/or grommets.
Part Alternates: AN83230, AN832-30, 7M637, 7M637BT3D, 7M637BT-3D, 10108748 , 4730-01-141-9665, 01-141-9665, 4730011419665, 011419665
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 09 NOV 1982 | 01-141-9665 | 03783 ( NIPPLE, TUBE ) |
Drawings & Photos | NSN 4730-01-141-9665
Demand History | NSN 4730-01-141-9665
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4730-01-141-9665 | 2022-03-90 | 16 | DIBBS |
| 4730-01-141-9665 | 2021-10-284 | 8 | DIBBS |
| 4730-01-141-9665 | 2020-07-203 | 8 | DIBBS |
| 4730-01-141-9665 | 2019-12-346 | 5 | DIBBS |
| 4730-01-141-9665 | 2018-08-242 | 5 | DIBBS |
| 4730-01-141-9665 | 2018-08-235 | 9 | DIBBS |
| 4730-01-141-9665 | 2018-05-137 | 5 | DIBBS |
| 7M637BT3D | 2011-11-314 | 1 | United States |
| 4730-01-141-9665 | 2010-03-63 | 7 | DIBBS |
| 4730-01-141-9665 | 2009-04-106 | 1 | DIBBS |
Cross Reference | NSN 4730-01-141-9665
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 7M637 | 76301 | BOEING COMPANY, THE DBA BOEING |
| 7M637BT-3D | 01673 | SPS TECHNOLOGIES, LLC DBA AIRDROME PRECISION COMPONENTS |
| 7M637BT-3D | 14397 | FABER ENTERPRISES, INC. |
| 7M637BT-3D | 14798 | DESIGNED METAL CONNECTIONS, INC. DBA PERMASWAGE |
| 7M637BT-3D | 52930 | NELSON AERO SPACE, INC. |
| 7M637BT-3D | 76301 | BOEING COMPANY, THE DBA BOEING |
| 7M637BT3D | 06581 | ALLAN AIRCRAFT SUPPLY CO, LLC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4730-01-141-9665
Related Products | NSN 4730-01-141-9665
Technical Data | NSN 4730-01-141-9665
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY OVERALL |
| SURFACE TREATMENT | ALUMINUM OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | MIL-C-83488,CL 3,TY 2 MIL SPEC SINGLE TREATMENT RESPONSE OVERALL |
| STYLE DESIGNATOR | A64 FLARED W/BULKHEAD THREAD |
| CONNECTION TYPE | THREADED EXTERNAL TUBE ALL ENDS |
| CONNECTION STYLE | B64 FLARED ALL ENDS |
| SEAT ANGLE | 37.0 DEGREES ALL ENDS |
| NOMINAL OUTSIDE DIAMETER TUBE ACCOMMODATED | 0.312 INCHES ALL ENDS |
| THREAD SERIES DESIGNATOR | UNF ALL ENDS UNF 1ST END BULKHEAD |
| NOMINAL THREAD SIZE | 0.375 INCHES ALL ENDS 0.375 INCHES 1ST END BULKHEAD |
| THREAD CLASS | 3A ALL ENDS 3A 1ST END BULKHEAD |
| NOMINAL OVERALL LENGTH | 1.859 INCHES |
| SPECIFICATION/STANDARD DATA | 88044-AN832 GOVERNMENT STANDARD |
| MANUFACTURERS CODE | 88044 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AN832-30 |
Restrictions/Controls & Freight Information | NSN 4730-01-141-9665
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051400 | PIPE FITTINGS ALUMINUM |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | KE | Naval ICP Philadelphia, PA 19111 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4730-01-141-9665
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
