NSN 4730-01-064-7927 M24063B23, M24063B-23, A STY A SZ 2 1-2 INCH
Product Details | SOUND ISOLATION INSERT SET
4730-01-064-7927 A multipiece item consisting of a nonmetallic positioning insert, thrust insert with a bonded washer and a metallic backup washer. It is specifically designed for use in a piping system sound isolation coupling flexible connector for the purpose of isolating sound.
Part Alternates: M24063B23, M24063B-23, A STY A SZ 2 1-2 INCH, ASTYASZ212INCH, STY A SZ 2 1-2 INCH, STY A SZ 2 1-2 INCH 80DUROMETER, STYASZ212INCH, STYASZ212INCH80DUROMETER, MILI24063, MIL-I-24063, MILI24063B23, MIL-I-24063B-23, 202994PC7ASSYG, 256548PC21250, 256548PC21-2-50, 2640069PC7ASSEMBLYG, 2640-069PC7ASSEMBLYG, 4730-01-064-7927, 01-064-7927, 4730010647927, 010647927
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 31 AUG 1978 | 01-064-7927 | 33462 ( INSERT SET, SOUND ISOLATION ) |
Cross Reference | NSN 4730-01-064-7927
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 202994PC7ASSYG | 43689 | HUNTINGTON INGALLS INCORPORATED DIV NEWPORT NEWS |
| 256548PC21-2-50 | 71905 | DERBYSHIRE MACHINE & TOOL CO |
| 2640-069PC7ASSEMBLYG | 96169 | ELECTRIC BOAT CORPORATION |
| A STY A SZ 2 1-2 INCH | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M24063B-23 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-I-24063 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-I-24063B-23 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| STY A SZ 2 1-2 INCH | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| STY A SZ 2 1-2 INCH 80DUROMETER | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-01-064-7927
Technical Data | NSN 4730-01-064-7927
| Characteristic | Specifications |
|---|---|
| COMPONENT QUANTITY | 3 |
| COMPONENT DOCUMENT ORIGIN | GOVERNMENT |
| DOCUMENT SOURCE | 81349 |
| DOCUMENT TYPE | MILITARY SPECIFICATION |
| DOCUMENT IDENTIFICATION | MIL-I-24063 STYLE A |
| COMPONENT DOCUMENT PAGE NUMBER | 7 |
| NONSUPPLY ITEMS AND QUANTITIES | FIG 1,PART 1,SIZE 2-1/2,DUROMETER SHORE A 80,POSITIONING INSERT 1; FIG 1,PART 2,SIZE 2-1/2 THRUST INSERT W/BONDED WASHER 1; FIG 1,PART 3,THRUST WASHER 1 |
| NONDEFINITIVE SPEC/STD DATA | A STYLE AND 1 FIGURE |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-I-24063B-23 |
Restrictions/Controls & Freight Information | NSN 4730-01-064-7927
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 052190 | PIPE,TUBING,OR PIPE OR TUBING FITTI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4730-01-064-7927
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 SE : Set |
