Product Details | TUBE TEE
4730-01-047-4090 A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The connections have machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or are unthreaded and designed to accommodate a tube. It may have side inlet(s). It is used as a junction at the intersection of a tube or tube fitting.
Part Alternates: 16P1391, 16P139-1, 4730-01-047-4090, 01-047-4090, 4730010474090, 010474090
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 07 SEP 1977 | 01-047-4090 | 03809 ( TEE, TUBE ) |
Drawings & Photos | NSN 4730-01-047-4090
Demand History | NSN 4730-01-047-4090
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4730-01-047-4090 | 2024-10-305 | 9 | DIBBS |
| 4730-01-047-4090 | 2024-03-67 | 9 | DIBBS |
| 4730-01-047-4090 | 2023-10-295 | 8 | DIBBS |
| 4730-01-047-4090 | 2021-01-03 | 6 | DIBBS |
| 4730-01-047-4090 | 2020-12-341 | 5 | DIBBS |
| 4730-01-047-4090 | 2020-05-146 | 8 | DIBBS |
| 4730-01-047-4090 | 2020-04-100 | 2 | DIBBS |
| 4730-01-047-4090 | 2019-05-139 | 5 | DIBBS |
| 4730-01-047-4090 | 2019-03-79 | 1 | United States |
| 4730-01-047-4090 | 2018-05-129 | 4 | DIBBS |
| 4730-01-047-4090 | 2018-02-57 | 4 | DIBBS |
| 4730-01-047-4090 | 2017-12-345 | 3 | US |
| 4730-01-047-4090 | 2017-12-341 | 3 | DIBBS |
| 4730-01-047-4090 | 2017-12-341 | 1 | DIBBS |
| 4730-01-047-4090 | 2017-07-205 | 4 | DIBBS |
| 4730-01-047-4090 | 2015-06-167 | 2 | DIBBS |
| 4730-01-047-4090 | 2012-03-68 | 2 | DIBBS |
| 4730-01-047-4090 | 2011-08-237 | 3 | DIBBS |
| 4730-01-047-4090 | 2011-03-70 | 3 | DIBBS |
Cross Reference | NSN 4730-01-047-4090
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 16P139-1 | 81755 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN AERONAUTICS |
