NSN 4730-00-836-8176 MS948305, MS9483-05, 00-836-8176
Product Details | TUBE FITTING BRAZING FERRULE
4730-00-836-8176 A flanged cylindrical metallic item designed to be slipped over tubing and brazed in place. The rear face of the flange forms a bearing surface for the coupling nut, and the front face is of a contour designed to seat against a mating contour on a fitting. When assembled the joint seals at the seat in a manner similar to a seat type union.
Part Alternates: MS948305, MS9483-05, 4730-00-836-8176, 00-836-8176, 4730008368176, 008368176
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 09 DEC 1966 | 00-836-8176 | 18024 ( FERRULE, BRAZING, TUBE FITTING ) |
