NSN 4730-00-805-3967 10865143, 00-805-3967, 008053967
Product Details | FLUID PRESSURE LINE MULTIPLE CONNECTOR
4730-00-805-3967 A device of varying shapes with two or more connections to accommodate hydraulic or air passage(s) line end connections and/or a BOLT, FLUID PASSAGE(S).
Part Alternates: 10865143, 4730-00-805-3967, 00-805-3967, 4730008053967, 008053967
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 01 JAN 1962 | 00-805-3967 | 18682 ( CONNECTOR, MULTIPLE, FLUID PRESSURE LINE ) |
Drawings & Photos | NSN 4730-00-805-3967
Cross Reference | NSN 4730-00-805-3967
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10865143 | 19207 | U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-00-805-3967
Technical Data | NSN 4730-00-805-3967
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL |
| SURFACE TREATMENT | CADMIUM |
| STYLE DESIGNATOR | D17 1 FLUID CONNECTION |
| OVERALL LENGTH | 1.810 INCHES NOMINAL |
| OVERALL WIDTH | 1.250 INCHES NOMINAL |
| THICKNESS | 1.000 INCHES NOMINAL |
| BOLT HOLE DIAMETER | 0.755 INCHES NOMINAL |
| DEG BETWEEN OUTLETS | 45.0 |
| FLUID CONNECTION QUANTITY | 1 |
| CONNECTION STYLE | G4 PLAIN |
| FLUID CONVEYANCE TYPE AND SIZE FOR WHICH DESIGNED | 1/2 IN. NOM PIPE |
| THREAD SIZE | 1/2 IN.-14 |
| SCREW THREAD SERIES DESIGNATOR | NPTF |
| THREAD DIRECTION | RIGHT-HAND |
| BOLT HOLE FLATS SERRATIONS | NOT PROVIDED |
| BOLT HOLE FLUID PASSAGE | PROVIDED |
Restrictions/Controls & Freight Information | NSN 4730-00-805-3967
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051450 | PIPE FITTINGS CUPRO NICKEL/COPPER |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
