NSN 4730-00-287-3053 MS208195D, MS20819-5D, AN322005
Product Details | TUBE FITTING FLARED SLEEVE
4730-00-287-3053 A flanged cylindrical metallic item designed to be used on tubing to back up the flared end and to provide a bearing surface for the coupling nut, thereby reducing wear on the tubing flare. The inside diameter of the flanged end is countersunk to form a seat for the flare when assembled to a mating fitting.
Part Alternates: MS208195D, MS20819-5D, AN322005, AN3220-05, ST7M4115W, ST7M411-5W, 6664921, 66649-21, 4730-00-287-3053, 00-287-3053, 4730002873053, 002873053
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 20 SEP 2001 | 00-287-3053 | 18027 ( SLEEVE, FLARED, TUBE FITTING ) |
Drawings & Photos | NSN 4730-00-287-3053
Demand History | NSN 4730-00-287-3053
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| ST7M411-5W | 2024-05-149 | 157 | DIBBS |
| ST7M411-5W | 2024-05-137 | 157 | DIBBS |
| ST7M411-5W | 2024-04-102 | 291 | DIBBS |
| ST7M411-5W | 2020-04-119 | 288 | DIBBS |
| MS208195D | 2017-03-81 | 30 | Brazil |
| MS208195D | 2017-03-66 | 1350 | United States |
| 4730-00-287-3053 | 2016-06-173 | 10 | us |
| ST7M4115W | 2016-06-162 | 5 | us |
| ST7M4115W | 2015-08-240 | 20 | us |
| MS208195D | 2015-08-240 | 20 | us |
| ST7M4115W | 2015-01-15 | 4 | us |
| 4730-00-287-3053 | 2014-10-301 | 10 | us |
| ST7M4115W | 2014-05-121 | 10 | US |
| ST7M4115W | 2014-02-55 | 16 | US |
| 4730-00-287-3053 | 2013-06-160 | 2336 | DIBBS |
| MS208195D | 2013-06-154 | 100 | United States |
| 4730-00-287-3053 | 2012-06-181 | 1170 | DIBBS |
| 4730-00-287-3053 | 2012-04-108 | 601 | DIBBS |
| MS208195D | 2011-09-256 | 50 | US |
| 4730-00-287-3053 | 2011-09-249 | 448 | DIBBS |
| MS208195D | 2011-05-129 | 50 | US |
Cross Reference | NSN 4730-00-287-3053
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 66649-21 | 80020 | NAVAL AIR WARFARE CENTER AIRCRAFT DIVISION CODE 4.8.8.0.0.B BLDG 148-2 |
| AN3220-05 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| MS20819-5D | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| ST7M411-5W | 01673 | SPS TECHNOLOGIES, LLC DBA AIRDROME PRECISION COMPONENTS |
| ST7M411-5W | 14397 | FABER ENTERPRISES, INC. |
| ST7M411-5W | 30974 | AEROFIT, LLC |
| ST7M411-5W | 52930 | NELSON AERO SPACE, INC. |
| ST7M411-5W | 59680 | B. & E. MANUFACTURING CO., INC. |
| ST7M411-5W | 66774 | PRECISION AIRCRAFT MACHINING COMPANY, INC. |
| ST7M411-5W | 76301 | BOEING COMPANY, THE DBA BOEING |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4730-00-287-3053
Related Products | NSN 4730-00-287-3053
Technical Data | NSN 4730-00-287-3053
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY, QQ-A-225/9, ALLOY 7075, T73 |
| SURFACE TREATMENT | ANODIZED, MIL-A-8625, TYPE 2 |
| METALLIC HARDNESS RATING | NOT RATED |
| CASEHARDENING INDICATOR | NOT CASEHARDENED |
| HOSE/TUBE OUTSIDE DIAMETER FOR WHICH DESIGNED | 0.313 INCHES NOMINAL |
| STYLE DESIGNATOR | M1 SLEEVE |
| OVERALL LENGTH | 0.438 INCHES NOMINAL |
| FLANGE WIDTH | 0.156 INCHES NOMINAL |
| FLANGE OUTSIDE DIAMETER | 0.445 INCHES NOMINAL |
| SEAT ANGLE IN DEG | 33.0 |
| SLEEVE OUTSIDE DIAMETER | 0.366 INCHES NOMINAL |
