NSN 4730-00-243-9581 4J2967, 00-243-9581, 002439581
Product Details | TUBE FITTING CLINCH SLEEVE
4730-00-243-9581 A flanged cylindrical item having a sharp cutting surface on the inside diameter at the end opposite the flange. The cutting edge, in use, is designed to imbed in the tubing due to pressure exerted when the outside diameter of the sleeve is forced into and against an angular seat. This firmly attaches the sleeve to the tubing and the flanged end then serves as a bearing surface for the coupling nut to bring the tubing into the mating fitting.
Part Alternates: 4J2967, 4730-00-243-9581, 00-243-9581, 4730002439581, 002439581
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 28 DEC 1971 | 00-243-9581 | 18025 ( SLEEVE, CLINCH, TUBE FITTING ) |
Cross Reference | NSN 4730-00-243-9581
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 4J2967 | 11083 | CATERPILLAR INC. DBA CATERPILLAR |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-00-243-9581
Technical Data | NSN 4730-00-243-9581
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL |
| METALLIC HARDNESS RATING | NOT RATED |
| OVERALL LENGTH | 1.594 INCHES NOMINAL |
| FLANGE WIDTH | 0.344 INCHES NOMINAL |
| SLEEVE OUTSIDE DIAMETER | 2.781 INCHES NOMINAL |
