NSN 4730-00-096-8934 SP233, UM2706, UM5008
Product Details | HOSE CLAMP
4730-00-096-8934 A clamp in which the body (band or wire) completely encircles an item and distributes a relatively even amount of pressure throughout the entire 360 degrees (6.282 radians) of the periphery of the item to be compressed. Its compression quality is dependent upon an integral screw mechanism, (screw, bolt spring compression and the like mechanical fasteners), or it may be applied by a device not integral with the clamp itself. It is specifically designed to prevent leakage between a hose and its attaching connection(s) when the body of the clamp is round or circular. For square, rectangular, or irregularly shaped items, see CLAMP, HOSE, SPECIAL-SHAPED. Excludes CLAMP, ELECTRICAL; CLAMP, LOOP; CLAMP, FIRE HOSE, SHUTOFF; FERRULE (as modified); and HAND SCREW.
Part Alternates: SP233, UM2706, UM5008, 11640805-1, 5008, 4730-00-096-8934, 00-096-8934, 4730000968934, 116408051, 000968934
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 15 DEC 1972 | 00-096-8934 | 13566 ( CLAMP, HOSE ) |
Drawings & Photos | NSN 4730-00-096-8934
Demand History | NSN 4730-00-096-8934
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| UM5008 | 2016-06-180 | 15 | Iraq |
| 4730-00-096-8934 | 2016-03-89 | 20 | United States |
Cross Reference | NSN 4730-00-096-8934
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 11640805-1 | 19207 | U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM |
| 5008 | 59199 | UNIVERSAL METAL PRODUCTS INC |
| SP233 | 00671 | SPECIALTY PRODUCTS CO DIV OF CLAMPCO PRODUCTS INC |
| SP233 | 54646 | CLAMPCO PRODUCTS, INC. DIV CLAMPCO PRODUCTS, INC. |
| UM2706 | 00671 | SPECIALTY PRODUCTS CO DIV OF CLAMPCO PRODUCTS INC |
| UM2706 | 54646 | CLAMPCO PRODUCTS, INC. DIV CLAMPCO PRODUCTS, INC. |
| UM5008 | 59919 | UNIQUE DATA SYSTEMS INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-00-096-8934
Technical Data | NSN 4730-00-096-8934
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-S-700 FED SPEC 1ST MATERIAL RESPONSE OVERALL |
| SURFACE TREATMENT | PHOSPHATE AND PAINT OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | TT-E-592 FED SPEC 1ST TREATMENT RESPONSE AND TT-E-485 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| STYLE DESIGNATOR | C27 BAND |
| INSIDE DIAMETER | 0.460 INCHES MINIMUM AND 0.545 INCHES MAXIMUM |
| OVERALL WIDTH | 0.312 INCHES NOMINAL |
| FASTENING DEVICE TYPE | SPRING TENSION |
| MANUFACTURERS CODE | 00671 |
| DESIGN CONTROL REFERENCE | UM2706 |
Restrictions/Controls & Freight Information | NSN 4730-00-096-8934
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
