NSN 4320-00-803-5826 G325AG, N300, 00-803-5826
Product Details | CENTRIFUGAL PUMP UNIT
4320-00-803-5826 An assembled unit consisting of a commonly mounted centrifugal pump(s), prime mover(s), and the necessary components to provide for a complete operation.
Part Alternates: G325AG, N300, 4320-00-803-5826, 00-803-5826, 4320008035826, 008035826
Pumps and Compressors | Power and Hand Pumps
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
43 | 08 APR 1968 | 00-803-5826 | 17988 ( PUMP UNIT, CENTRIFUGAL ) |
Demand History | NSN 4320-00-803-5826
Part Number | Request Date | QTY | Origin |
---|---|---|---|
N300 | 2023-10-283 | 2 | US |
N300 | 2020-08-240 | 1 | US |
N300 | 2019-03-67 | 6 | IN |
N300 | 2017-07-207 | 1 | United States |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 4320-00-803-5826
Related Products | NSN 4320-00-803-5826
Technical Data | NSN 4320-00-803-5826
Characteristic | Specifications |
---|---|
MAXIMUM DISCHARGE FLOW RATE | 5.0 GALLONS PER MINUTE |
SUCTION LIFT | 1.000 FEET |
MEDIA FOR WHICH DESIGNED | WATER, FRESH |
PUMPING ELEMENT OPERATING POSITION | HORIZONTAL |
CENTRIFUGAL PUMP DESIGN | MIXED FLOW |
CENTRIFUGAL PUMP IMPELLER QUANTITY | 1 |
CENTRIFUGAL PUMP IMPELLER SUCTION TYPE | SINGLE |
STAGE QUANTITY | 1 |
FEATURES PROVIDED | SELF-PRIMING |
OPERATION RELATIONSHIP DESIGN | SIMULTANEOUS |
PUMP QUANTITY | 1 |
DISCHARGE CONNECTION QUANTITY | 1 |
DISCHARGE CONNECTION TYPE | THREADED EXTERNAL |
DISCHARGE CONNECTION THREAD SIZE AND SERIES/TYPE DESIGNATOR | 0.375-18 NPT |
PRIME MOVER TYPE | ELECTRIC MOTOR |
PRIME MOVER COOLING MEDIUM | WATER, FRESH |
PRIME MOVER QUANTITY | 1 |
PRIME MOVER POWER RATING | 0.025 HORSEPOWER |
CURRENT TYPE | AC |
VOLTAGE IN VOLTS | 115.0 |
FREQUENCY IN HERTZ | 60.0 |
PHASE | SINGLE |
CURRENT RATING IN AMPS | 0.8 |
INCLOSURE TYPE | FULLY INCLOSED |
ENVIRONMENTAL PROTECTION | SUBMERSIBLE |
COOLING METHOD | WATER COOLED |
SPECIAL FEATURES | 6.0 FT POWER CORD PROVIDED |
III UNPACKAGED UNIT LENGTH | 4.000 INCHES NOMINAL |
III UNPACKAGED UNIT WIDTH | 2.2500 INCHES NOMINAL |
III UNPACKAGED UNIT HEIGHT | 4.875 INCHES NOMINAL |
III PUMP BASIC MATERIAL | PLASTIC |
(NON-CORE DATA) INTEGRAL STRAINER | INCLUDED |
(NON-CORE DATA) SUBMERSIBILITY | SUBMERSIBLE |
Restrictions/Controls & Freight Information | NSN 4320-00-803-5826
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | U | Precious metal type is unknown |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 128000 | PUMPS PWR NOI/WORKING HEADS/PARTS |
Less than car load rating | ||
Less than truck load rating | M | 85.0 |
Water commodity Code | 594 | unknown |
Originating Activity Code | PA | Marine Corps Logistics Base Albany, GA 31704-1128 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4320-00-803-5826
Category | Code | Description |
---|---|---|
Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DF | Department of the Air Force |
Service Organization | F | U.S. Air Force |
Reparability | N | Stock Fund (except Munitions) |
Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
Combat Essentiality Code | 2 | Non-Critical Repair Part. Repair parts or major components whose failure in an end item will not render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency, and which do not fit the definition of Code 3 or 4 items. |
Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DM | U.S. Marine Corps |
Service Organization | M | U.S. Marine Corps |
Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
