Product Details | TUBEAXIAL FAN

4140-01-142-8340 A nonpositive displacement mechanical device without guide vanes and having an axial fan impeller inclosed within a tubular housing. It is designed primarily for duct installation to move air or gas axially over a wide range of volumes at medium pressures.20316800000259000004140000000

Part Alternates: 16E651, 16E65-1, 16E731, 16E73-1, 4140-01-142-8340, 01-142-8340, 4140011428340, 011428340

Refrigeration, Air Conditioning, and Air Circulating Equipment | Fans, Air Circulators, and Blower Equipment

Supply Group (FSG) NSN Assign. NIIN
41 21 NOV 1982 01-142-8340

Drawings & Photos | NSN 4140-01-142-8340


Cross Reference | NSN 4140-01-142-8340

Part Number Cage Code Manufacturer
16E65-1 72914 GRIMES AEROSPACE COMPANY DBA HONEYWELL
16E73-1 72914 GRIMES AEROSPACE COMPANY DBA HONEYWELL

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 4140-01-142-8340

Technical Data | NSN 4140-01-142-8340

Characteristic Specifications
STYLE DESIGNATOR 31 FIXED
LENGTH 7.000 INCHES NOMINAL
HOUSING INSIDE DIAMETER 7.125 INCHES NOMINAL
MATERIAL ALUMINUM ALLOY 6061 OVERALL
SURFACE TREATMENT CHROMATE ZINC OVERALL
DRIVE TYPE DIRECT
ROTATION DIRECTION FOR WHICH DESIGNED COUNTERCLOCKWISE
PRIME MOVER TYPE ELECTRIC MOTOR
SPEED ADJUSTMENTS SINGLE SPEED
PRIME MOVER DRIVE SHAFT BEARING TYPE BALL
INCLOSURE TYPE FULLY INCLOSED
AMBIENT TEMP AT FULL RATED POWER -29.0 DEG CELSIUS AND 71.0 DEG CELSIUS
ELECTRICAL CONNECTION TYPE CONNECTOR PLUG
PRIME MOVER POWER RATING 1.600 HORSEPOWER
OPERATING SPEED AT RATED CAPACITY IN RPM 11300.0
VOLTAGE IN VOLTS AND CURRENT TYPE 440.0 AC
PHASE THREE
FREQUENCY IN HERTZ 400.0
AIR FLOW RATE 706.0 CUBIC FEET PER MINUTE NOMINAL
STATIC PRESSURE AT SPECIFIED AIR FLOW RATE 0.0 INCHES OF WATER
FLOW DIRECTION INWARD
MOUNTING FACILITY TYPE AND QUANTITY 6 UNTHREADED HOLE
MANUFACTURERS CODE 72914
DESIGN CONTROL REFERENCE 16E65-1

Restrictions/Controls & Freight Information | NSN 4140-01-142-8340

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 061920 FANS ELEC NOI IN BARREL/BOX/CRATE
Less than car load rating
Less than truck load rating J 100.2
Water commodity Code 752 unknown
Originating Activity Code CX Defense Supply Center Richmond
Richmond, VA 23297-5000
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 4140-01-142-8340

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
