NSN 4030-00-132-9162 MS184426, MS1844-26, MS1844C
Product Details | WIRE ROPE SWAGING SLEEVE
4030-00-132-9162 A compression fitting designed to make a permanent eye, lap, or running splice on an item.
Part Alternates: MS184426, MS1844-26, MS1844C, MS51844, MS5184424, MS51844-24, MS5184426, MS51844-26 , MS5184484, MS51844-84, MS5184486, MS51844-86, MS51844C , SMD4236511, SMD423651-1, 10606518-3, 1286VX, 128-6VX, 170016, 17001-6, 186X, 18-6X, 18-6-X, 3147201, 314720-1, 3522T16, 400211, 0151957000, 015-1957-000, 4284VM, 428-4VM, 4030-00-132-9162, 00-132-9162, 4030001329162, 001329162, 106065183
Rope, Cable, Chain, and Fittings | Fittings for Rope, Cable, and Chain
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 40 | 01 JAN 1961 | 00-132-9162 | 16283 ( SWAGING SLEEVE, WIRE ROPE ) |
Drawings & Photos | NSN 4030-00-132-9162
Demand History | NSN 4030-00-132-9162
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4030-00-132-9162 | 2022-12-349 | 2 | US |
| MS51844 | 2021-06-159 | 89 | US |
| MS5184484 | 2020-09-246 | 1 | United States |
| 4030-00-132-9162 | 2020-06-182 | 1 | US |
| MS5184424 | 2020-03-86 | 30 | Brazil |
| MS5184424 | 2018-09-254 | 100 | United States |
| MS51844-26 | 2018-05-121 | 130 | United States |
| 4030-00-132-9162 | 2015-12-348 | 1 | DIBBS-RFPs |
| 170016 | 2015-11-322 | 4 | US |
| 4030-00-132-9162 | 2015-08-223 | 22955 | DIBBS |
| 4030-00-132-9162 | 2015-08-214 | 22955 | DIBBS |
| 4030-00-132-9162 | 2015-05-142 | 4 | US |
| MS51844 | 2014-08-217 | 4 | US |
| MS51844 | 2014-08-217 | 4 | US |
| 400211 | 2014-04-113 | 30 | US |
| MS5184424 | 2013-11-326 | 96 | United States |
| MS5184424 | 2012-01-20 | 4 | United States |
| MS5184424 | 2012-01-03 | 20 | United States |
| MS51844 | 2011-10-298 | 2 | United States |
| MS51844C | 2011-05-122 | 50 | US |
| 4030-00-132-9162 | 2010-03-78 | 6 | United States |
| MS51844 | 2007-11-334 | 50 | Canada |
Cross Reference | NSN 4030-00-132-9162
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 015-1957-000 | 13499 | ROCKWELL COLLINS, INC. DBA GOVERNMENT SYSTEMS |
| 10606518-3 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 128-6VX | 76691 | NATIONAL TELEPHONE SUPPLY COMPANY, THE |
| 17001-6 | 78702 | WADE ANTENNA INC DBA TACO ANTENNA |
| 18-6-X | 62809 | MARINE ACQUISITION (US) INCORPORATED DBA SEASTAR SOLUTIONS |
| 18-6X | 76691 | NATIONAL TELEPHONE SUPPLY COMPANY, THE |
| 314720-1 | 80020 | NAVAL AIR WARFARE CENTER AIRCRAFT DIVISION CODE 4.8.8.0.0.B BLDG 148-2 |
| 3522T16 | 39428 | MCMASTER-CARR SUPPLY COMPANY |
| 400211 | F4665 | SOCIETE NOUVELLE CENTRAIR |
| 428-4VM | 76691 | NATIONAL TELEPHONE SUPPLY COMPANY, THE |
| MS51844 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS51844-26 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS51844-84 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS51844-86 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS51844C | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| SMD423651-1 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4030-00-132-9162
Related Products | NSN 4030-00-132-9162
Technical Data | NSN 4030-00-132-9162
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY 102 OR COPPER ALLOY 103 OR COPPER ALLOY 108 OR COPPER ALLOY 120 OR COPPER ALLOY 122 OR COPPER ALLOY 142 |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-T-24107 MIL SPEC ALL MATERIAL RESPONSES |
| SURFACE TREATMENT | ZINC |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-Z-325,TY 1 CL 2 FED SPEC SINGLE TREATMENT RESPONSE |
| STYLE DESIGNATOR | 160 FIGURE 8 |
| OVERALL WIDTH | 0.432 INCHES MINIMUM AND 0.450 INCHES MAXIMUM |
| OVERALL LENGTH | 1.000 INCHES NOMINAL |
| OVERALL HEIGHT | 0.659 INCHES MINIMUM AND 0.679 INCHES MAXIMUM |
| ACCOMMODATED MATERIAL DIAMETER | 0.188 INCHES NOMINAL |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS1844-26 |
| MANUFACTURERS CODE | 96906 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS1844C |
Restrictions/Controls & Freight Information | NSN 4030-00-132-9162
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 105200 | FITTINGS CABLE/CHAIN/ROPE I/S |
| Less than car load rating | ||
| Less than truck load rating | U | 50.0 |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4030-00-132-9162
Army
Air Force
Navy
Marines| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
H EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
H EA : Each |
| Category | Code | Description |
|---|---|---|
| Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
| Combat Essentiality Code | 2 | Non-Critical Repair Part. Repair parts or major components whose failure in an end item will not render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency, and which do not fit the definition of Code 3 or 4 items. |
| Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
| Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
| Echelon Identification Code | B | Consumable Repair Parts |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DM | U.S. Marine Corps |
| Service Organization | M | U.S. Marine Corps |
| Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
H EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
H EA : Each |
