NSN 3456-00-022-9932 000229932
Product Details | TUBE EXPANDER
3456-00-022-9932 A tool used on closed sided and/or hollow metal parts to form precise shapes and dimensions by systems of dies which expand outward and stretch the metal to a required shape and size.
Part Alternates: 000229932
Metalworking Machinery | Bending and Forming Machines
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 34 | 00-022-9932 | 37288 ( EXPANDER, TUBE ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3456-00-022-9932
Related Products | NSN 3456-00-022-9932
Technical Data | NSN 3456-00-022-9932
| Characteristic | Specifications |
|---|---|
| DESIGN TYPE | PLAIN |
| EXPANDER TYPE | ROLLER |
| ROLLER TYPE | TAPERED |
| ROLLER QUANTITY | 3 |
| ROLLER EFFECTIVE LENGTH | 1.250 INCHES NOMINAL |
| MANDREL TYPE | ONE PIECE SQUARE HEAD |
| QUANTITY | 1 |
| OVERALL LENGTH | 5.375 INCHES NOMINAL |
| OPERATION METHOD | HAND OR POWER |
| FLEXIBLE TIP | NOT INCLUDED |
| TAPERED PORTION LENGTH | 4.500 INCHES NOMINAL |
| SQUARE HEAD WIDTH ACROSS FLATS | 0.500 INCHES NOMINAL |
| HEAD SQUARE LENGTH | 0.750 INCHES NOMINAL |
| HAND TURNING ROD | NOT INCLUDED |
| MANUFACTURERS CODE | 58529 |
| DESIGN CONTROL REFERENCE | 1627FPC3650 TO 3659/34084/ |
Restrictions/Controls & Freight Information | NSN 3456-00-022-9932
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
