NSN 3417-01-239-5402 1061775, 106-1775, 01-239-5402
Product Details | VERTICAL MILLING MACHINE
3417-01-239-5402 00001013417000000
Part Alternates: 1061775, 106-1775, 3417-01-239-5402, 01-239-5402, 3417012395402, 012395402
Metalworking Machinery | Milling Machines
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 34 | 30 AUG 1986 | 01-239-5402 | 03161 ( MILLING MACHINE, VERTICAL0 ) |
Cross Reference | NSN 3417-01-239-5402
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 106-1775 | 20528 | ENCO MFG CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3417-01-239-5402
Related Products | NSN 3417-01-239-5402
Technical Data | NSN 3417-01-239-5402
| Characteristic | Specifications |
|---|---|
| MOUNTING TYPE | FLOOR |
| TABLE TYPE | PLAIN |
| LENGTH | 22.000 INCHES NOMINAL |
| WIDTH | 10.000 INCHES NOMINAL |
| TABLE LONGITUDINAL TRAVEL | 14.500 INCHES NOMINAL |
| TABLE CROSS TRAVEL | 7.000 INCHES NOMINAL |
| SPINDLE TYPE | VERTICAL SLIDING |
| SPINDLE ADJUSTMENT | 3.000 INCHES NOMINAL |
| MAXIMUM DISTANCE FROM SPINDLE NOSE TO WORKING SURFACE | 20.000 INCHES |
| HEAD TYPE | SWIVEL |
| HEAD ADJUSTMENT | 12.500 INCHES NOMINAL |
| POWER SOURCE | ELECTRIC MOTOR |
| QUANTITY | 3 |
| ELECTRIC MOTOR HORSEPOWER RATING | 1.000 |
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 220.0 |
| CURRENT RATING IN AMPS | 5.5 |
| FREQUENCY IN HERTZ | 60.0 |
| PHASE | THREE |
| FURNISHED ITEMS AND QUANTITY | COLLETS,5;CLAMPING KIT,1;PWR TBL FEED |
| SPECIAL FEATURES | HEAD ROTATES 90 DEG R/L;FWD/RVS SWITCH;HI/LOW SPEED;BUILT IN COOLANT SYSTEM 1/8 HP MTR |
| MANUFACTURERS CODE | 20528 |
| DESIGN CONTROL REFERENCE | 106-1775 |
Restrictions/Controls & Freight Information | NSN 3417-01-239-5402
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | M | HANDTOOLS AND SHOP EQUIPMENT |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72E | unknown |
| Originating Activity Code | TG | Warner-Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3417-01-239-5402
Air Force| Category | Code | Description |
|---|---|---|
| Price Validation | E | The current standard price is an estimated price.
|
| Budget Code | Y | variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly. |
| Source of Supply | FLZ | Warner Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | U | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | M | HANDTOOLS AND SHOP EQUIPMENT |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
