Product Details | VERTICAL MILLING MACHINE

3417-00-222-0918 00001013417000000

Part Alternates: 341722223434, 3417-2222-3434, 3H, 3417-00-222-0918, 00-222-0918, 3417002220918, 002220918

Metalworking Machinery | Milling Machines

Supply Group (FSG) NSN Assign. NIIN
34 01 JAN 1963 00-222-0918

Drawings & Photos | NSN 3417-00-222-0918


Demand History | NSN 3417-00-222-0918

Part Number Request Date QTY Origin
3H 2024-01-24 4 United States

Cross Reference | NSN 3417-00-222-0918

Part Number Cage Code Manufacturer
3H 16074 FIVES GIDDINGS & LEWIS, LLC DBA FIVES GIDDINGS & LEWIS
3H 32850 GIDDINGS AND LEWIS INC AUTOMATION TECHNOLOGY DIV

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 3417-00-222-0918

Technical Data | NSN 3417-00-222-0918

Characteristic Specifications
MOUNTING TYPE FLOOR
TABLE TYPE PLAIN
LENGTH 64.000 INCHES NOMINAL
WIDTH 13.500 INCHES NOMINAL
TABLE LONGITUDINAL TRAVEL 34.000 INCHES NOMINAL
TABLE CROSS TRAVEL 12.000 INCHES NOMINAL
TABLE VERTICAL TRAVEL 17.000 INCHES NOMINAL
SPINDLE TYPE FIXED
MAXIMUM DISTANCE FROM SPINDLE NOSE TO WORKING SURFACE 19.062 INCHES
HEAD TYPE ADJUSTABLE VERTICAL
HEAD ADJUSTMENT 6.000 INCHES NOMINAL
POWER SOURCE ELECTRIC MOTOR
QUANTITY 1
ELECTRIC MOTOR HORSEPOWER RATING 7.500
CURRENT TYPE AC
VOLTAGE IN VOLTS 220.0
CURRENT RATING IN AMPS NOT RATED
FREQUENCY IN HERTZ 60.0
PHASE THREE
MANUFACTURERS CODE 16074
DESIGN CONTROL REFERENCE 3H

Restrictions/Controls & Freight Information | NSN 3417-00-222-0918

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:QStrategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.”
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 133300 MACHINERY/MACHINES NOI
Less than car load rating J 100.2
Less than truck load rating W Rating Variable
Water commodity Code 72E unknown
Originating Activity Code XX
Air Dimension Code Z Shipment is not a consolidation, but does exceed 72 inches in one or more dimensions.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code Z unknonwn
HAZMAT
Type of Cargo 2 Type cargo code not applicable (for Air Force internal use).

Management | NSN 3417-00-222-0918

Category Code Description
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Budget CodeY variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly.
Source of SupplyFLZWarner Robins Air Logistics Center
Robins AFB, GA 31098-5609
AgencyDFDepartment of the Air Force
Service OrganizationLLead Service - 22 (Repairable)
ReparabilitySAF Equipment Management System (AFEMS)
Acquisition Advice CodesVTERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
