NSN 3120-01-508-9176 MS1410410, MS14104-10 , MS1410410P
Product Details | SELF-ALIGNING PLAIN BEARING
3120-01-508-9176 A detachable assembly in or on which a journal, gudgeon, pivot, or the like moves. It is used to carry a load and to reduce sliding friction. It does not employ rolling elements. The item consists of a bored precision ground ball (or spherical plain bearing) around which an outer ring is fitted. The assembly may be either separable or nonseparable. Excludes BEARING, PLAIN, ROD END and BEARING, PLAIN, SPHERICAL.
Part Alternates: MS1410410, MS14104-10 , MS1410410P, MS14104-10P, 51700100, 517-001-00 , 3120-01-508-9176, 01-508-9176, 3120015089176, 015089176
Bearings | Bearings, Plain, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 05 JUN 2003 | 01-508-9176 | 13208 ( BEARING, PLAIN, SELF-ALIGNING ) |
Drawings & Photos | NSN 3120-01-508-9176
Demand History | NSN 3120-01-508-9176
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS1410410 | 2024-12-346 | 15 | US |
| MS1410410 | 2023-05-136 | 610 | US |
| MS1410410 | 2020-12-345 | 48 | United States |
| MS1410410 | 2020-10-281 | 3 | United Arab Emirates |
| MS1410410 | 2020-04-112 | 600 | us |
| MS1410410 | 2019-05-137 | 3 | United States |
| MS1410410 | 2019-01-28 | 16 | United States |
| MS1410410 | 2017-07-205 | 2 | United States |
| 3120-01-508-9176 | 2017-05-132 | 2 | US |
| MS1410410 | 2013-12-339 | 1 | United States |
| MS1410410 | 2012-11-310 | 50 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 3120-01-508-9176
Technical Data | NSN 3120-01-508-9176
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 440C INNER MEMBER STEEL COMP 630 OUTER RACE MEMBER PLASTIC POLYTETRAFLUOROETHYLENE RACE LINER |
| SURFACE TREATMENT | PASSIVATE INNER MEMBER CADMIUM AND CHROMATE OUTER RACE MEMBER |
| STYLE DESIGNATOR | 11A WITH INSERT AND/OR LINER |
| BORE DIAMETER | 0.6245 INCHES MINIMUM AND 0.6250 INCHES MAXIMUM |
| OUTER MEMBER OUTSIDE DIAMETER | 1.1870 INCHES MINIMUM AND 1.1875 INCHES MAXIMUM |
| OUTER MEMBER WIDTH | 0.4950 INCHES MINIMUM AND 0.5050 INCHES MAXIMUM |
| INNER MEMBER WIDTH | 0.6230 INCHES MINIMUM AND 0.6250 INCHES MAXIMUM |
| III END ITEM IDENTIFICATION | KQ-4A GLOBAL HAWK |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | BEARING,PLAIN,SELF-LUBRICATING,SE LF-ALIGNING,LOW SPEED,NARROW,CHAMFEREDOUTER RING.-65 TO 325 0 DEG F |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS14104-10P |
Restrictions/Controls & Freight Information | NSN 3120-01-508-9176
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
