NSN 3110-00-271-0010 BACB10C SH 17 , BACB10C162H , BACB10CSH17

Product Details | AIRFRAME ROLLER BEARING

3110-00-271-0010 A cylindrical item in which the inner or outer ring turns upon row(s) of hardened ROLLER, BEARING which roll on a raceway, thus minimizing friction. These items are characterized by their noncorrosive qualities, lightness of weight, inch dimensions rather than metric, inner rings generally projecting beyond the faces of the outer ring, or a very narrow width inner ring having an outside diameter slightly larger than the bore diameter. Designed primarily for use in aircraft assemblies, such as control systems and surfaces of aircraft. Excludes BEARING, ROLLER, CYLINDRICAL.

Part Alternates: BACB10C SH 17 , BACB10C162H , BACB10CSH17, DSRP6, DSRP6FS160, DSRP6FS428, DSRP6FS464, DSRP6MILG23827, DSRP6MIL-G-23827, DSRP6MILG3278, 3110-00-271-0010, 00-271-0010, 3110002710010, 002710010

Bearings | Bearings, Antifriction, Unmounted

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
31	01 JAN 1963	00-271-0010	00046 ( BEARING, ROLLER, AIRFRAME )

Drawings & Photos | NSN 3110-00-271-0010

Part Number	Request Date	QTY	Origin
DSRP6FS464	2024-11-309	8	AE
BACB10C162H	2023-01-24	69	DIBBS
BACB10C162H	2023-01-16	69	DIBBS
BACB10C162H	2022-10-289	9	DIBBS
BACB10C162H	2022-07-198	17	DIBBS
BACB10C162H	2022-04-107	8	DIBBS
BACB10C162H	2022-01-25	18	DIBBS
BACB10C162H	2021-10-290	7	DIBBS
BACB10C162H	2021-07-196	40	DIBBS
3110-00-271-0010	2020-10-304	1	DIBBS-RFPs
BACB10C162H	2020-03-65	129	DIBBS
3110-00-271-0010	2019-10-291	6	GU
BACB10C162H	2019-05-134	129	DIBBS
3110-00-271-0010	2017-08-227	3	US
3110-00-271-0010	2017-08-226	80	US
3110-00-271-0010	2017-08-226	3	US
3110-00-271-0010	2017-08-226	25	US
3110-00-271-0010	2017-08-226	75	US
3110-00-271-0010	2016-09-256	20	US
DSRP6FS160	2015-09-251	2	US
3110-00-271-0010	2013-09-249	70	United States
3110-00-271-0010	2013-04-120	358	DIBBS
DSRP6FS160	2012-08-222	30	Chile
3110-00-271-0010	2012-06-159	2	United States
3110-00-271-0010	2012-06-159	9	United States
3110-00-271-0010	2012-05-139	9	United States
DSRP6FS160	2012-01-24	30	US
DSRP6FS160	2011-04-118	14	US
3110-00-271-0010	2011-02-54	500	United States
3110-00-271-0010	2011-02-54	100	United States
3110-00-271-0010	2010-12-357	1	United States
3110-00-271-0010	2010-05-125	4	DIBBS
3110-00-271-0010	2009-06-175	157	DIBBS
3110-00-271-0010	2009-05-126	88	DIBBS
DSRP6FS160	2008-08-241	80	US
3110-00-271-0010	2008-08-234	35	DIBBS
3110-00-271-0010	2008-06-158	51	DIBBS
3110-00-271-0010	2008-04-94	34	DIBBS
3110-00-271-0010	2008-01-08	64	DIBBS
3110-00-271-0010	2007-11-306	87	DIBBS
3110-00-271-0010	2007-08-220	47	DIBBS
DSRP6	2006-11-314	4	United States

Cross Reference | NSN 3110-00-271-0010

Part Number	Cage Code	Manufacturer
BACB10C SH 17	81205	THE BOEING COMPANY DBA BOEING
BACB10C162H	3NPS1	RBC AIRCRAFT PRODUCTS, INC.
BACB10C162H	73134	ROLLER BEARING COMPANY OF AMERICA, INC.
BACB10C162H	81205	THE BOEING COMPANY DBA BOEING
DSRP6	21335	TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE
DSRP6FS160	21335	TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE
DSRP6FS160	3NPS1	RBC AIRCRAFT PRODUCTS, INC.
DSRP6FS428	3NPS1	RBC AIRCRAFT PRODUCTS, INC.
DSRP6MIL-G-23827	21335	TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE
DSRP6MILG3278	21335	TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 3110-00-271-0010

Compare

Related Products | NSN 3110-00-271-0010

3110-00-271-0011, 3110-00-271-0015, 3110-00-271-0036, 3110-00-271-0037, 3110-00-271-0039

Technical Data | NSN 3110-00-271-0010

Characteristic	Specifications
MATERIAL	STEEL INNER RING STEEL OUTER RING STEEL ROLLER RUBBER SYNTHETIC SEAL
SURFACE TREATMENT	CADMIUM ALL EXTERNAL/EXPOSED METAL SURFACES
STYLE DESIGNATOR	272 CONCAVE ROLLER, DOUBLE CLOSURE, SELF ALIGNING
BORE DIAMETER	0.3750 INCHES NOMINAL
OVERALL OUTSIDE DIAMETER	1.4375 INCHES NOMINAL
OUTER RING WIDTH	0.7500 INCHES NOMINAL
INNER RING WIDTH	0.9370 INCHES NOMINAL
LUBRICATION MATERIAL	GREASE
LUBRICATION MATERIAL DOCUMENT AND CLASSIFICATION	MIL-G-23827 MIL SPEC SINGLE MATERIAL RESPONSE
SEAL QUANTITY	2
BEARING SEAL TYPE	CONTACT
SPECIAL FEATURES	10 DEG SELF ALIGNMENT IN EITHER DIRECTION

Restrictions/Controls & Freight Information | NSN 3110-00-271-0010

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	N	There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Precious Metals Indicator Code:	U	Precious metal type is unknown
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.

Category	Code	Description
NMF Description	114820	BEARINGS/BUSHINGS NOI BALL/ROLLER
Less than car load rating
Less than truck load rating	P	77.5
Water commodity Code	742	unknown
Originating Activity Code	XX
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	V	Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Management | NSN 3110-00-271-0010

Category	Code	Description
Materiel Category and Inventory Manager	T	Industrial Supplies (DLA/GSA Items)
Appropriation and Budget Activity	2	Stock Fund Secondary Items
Management Inventory Segment	2	NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code	B	Rotary Wing Aircraft
Weapons Systems/End Item or Homogeneous Group	BK	CH-47
Accounting Requirements Code	X	Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DA	Department of the Army
Service Organization	A	U.S. Army
Reparability	Z	This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Price Validation	V	The current standard price has been validated. The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range. The item was procured under open competition and under the competitive arena the price is considered fair and reasonable. ZOP or Standard price challenges are permissible but must be supported by adequate justification.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Cognizance Codes	9B	Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DN	Department of the Navy
Service Organization	N	U.S. Navy
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each
