NSN 3110-00-142-4358 M93561, BT359S, ST777
Product Details | TAPERED ROLLER BEARING CONE AND ROLLERS
3110-00-142-4358 An assembled inner component of a tapered roller bearing, consisting of a cone (which provides a contact surface for the rolling elements of the bearing), a complement of tapered rollers (the rolling elements), and frequently a retainer (which spaces the rolling elements).
Part Alternates: M93561, BT359S, ST777, V1116805, V4338X, PX733, JD7231, K359S, D417, 10618, 10688, 121564, 140167, 148147, 181794, 22B289, 252957, 2B172, 2EB2355, 2F7779, 2X698A, 308203, 3595, 359S, 3947516, 40957, 40H103, 417, 434811, 46504R, 5123596, 512-359-6, 51848, 52143, 5501521, 550152-1, 59631, 611240, 61-1240, 71204, 71470, 71608, 71757, 81204, 81570, 81757, 3110-00-142-4358, 00-142-4358, 3110001424358, 001424358
Bearings | Bearings, Antifriction, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 01 JAN 1961 | 00-142-4358 | 00023 ( CONE AND ROLLERS, TAPERED ROLLER BEARING ) |
Drawings & Photos | NSN 3110-00-142-4358
Demand History | NSN 3110-00-142-4358
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 3110-00-142-4358 | 2014-02-54 | 63 | DIBBS |
| 3110-00-142-4358 | 2011-10-280 | 8 | DIBBS |
| 71608 | 2011-08-235 | 5 | |
| 3110-00-142-4358 | 2011-05-126 | 10 | DIBBS |
| 71608 | 2010-10-291 | 3 | |
| 71608 | 2010-08-230 | 3 | United States |
Cross Reference | NSN 3110-00-142-4358
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10618 | 13125 | CLEVELAND TRENCHER CO INC |
| 10688 | 13125 | CLEVELAND TRENCHER CO INC |
| 121564 | 24617 | GENERAL MOTORS CORP |
| 140167 | 23862 | MILITARY VEHICLES OPN GENERAL MOTORS TRUCK AND BUS GROUP |
| 140167 | 24617 | GENERAL MOTORS CORP |
| 140167 | 7X677 | GENERAL MOTORS LLC DBA GENERAL MOTORS |
| 148147 | 08683 | BROCKWAY MOTOR TRUCKS DIV OF MACK TRUCKS INC |
| 181794 | 58275 | SASCO INC CANADIAN DIV |
| 22B289 | 62265 | VOLVO TRUCKS NORTH AMERICA INC. DBA FOREIGN PARENT IS VOLVO |
| 252957 | 6N299 | AGCO CORP PARTS OPN |
| 2B172 | 56442 | DIAMOND REO TRUCK CO |
| 2EB2355 | 56442 | DIAMOND REO TRUCK CO |
| 2F7779 | 11083 | CATERPILLAR INC. DBA CATERPILLAR |
| 2X698A | 95201 | NAPCO INTERNATIONAL LLC |
| 308203 | 12204 | DAIMLER CHRYSLER |
| 308203 | 18113 | CHRYSLER CORP HAMTRAMCK ASSEMBLY |
| 3595 | 01212 | FEDERAL-MOGUL CORP GOVERNMENT SALES DEPT |
| 3595 | 51588 | RBC BEARINGS INCORPORATED DIV WEST TRENTON DIVISION |
| 3595 | 60038 | TIMKEN CORPORATION, THE |
| 359S | 09605 | BOMAG USA SUB OF UNITED DOMINION INDUSTRIES |
| 359S | 53035 | NSK CORP BEARING DIV |
| 359S | 60038 | TIMKEN CORPORATION, THE |
| 359S | 61220 | TYSON BEARING CO DIV SKF INDUSTRIES INC |
| 3947516 | 62265 | VOLVO TRUCKS NORTH AMERICA INC. DBA FOREIGN PARENT IS VOLVO |
| 40957 | 13125 | CLEVELAND TRENCHER CO INC |
| 40H103 | 65282 | WHITE MOTOR CORP |
| 417 | 13125 | CLEVELAND TRENCHER CO INC |
| 434811 | 12204 | DAIMLER CHRYSLER |
| 46504R | 56442 | DIAMOND REO TRUCK CO |
| 512-359-6 | 66155 | PORTA DRILL INC |
| 512-359-6 | 95019 | DANA CORP SPICER TRANSMISSION DIV |
| 51848 | 34623 | AM GENERAL, LLC |
| 52143 | 42271 | KENOSHA AUTOMOTIVE PLANT SUB OF AMERICAN MOTORS CORP |
| 550152-1 | 95019 | DANA CORP SPICER TRANSMISSION DIV |
| 59631 | 65282 | WHITE MOTOR CORP |
| 61-1240 | 23040 | FORD MOTOR CO FORD PARTS AND SERVICE DIV |
| 61-1240 | 57526 | FORD MOTOR CO |
| 611240 | 23040 | FORD MOTOR CO FORD PARTS AND SERVICE DIV |
| 71204 | 13125 | CLEVELAND TRENCHER CO INC |
| 71470 | 13125 | CLEVELAND TRENCHER CO INC |
| 71608 | 13125 | CLEVELAND TRENCHER CO INC |
| 71757 | 13125 | CLEVELAND TRENCHER CO INC |
| 81204 | 13125 | CLEVELAND TRENCHER CO INC |
| 81570 | 13125 | CLEVELAND TRENCHER CO INC |
| 81570 | 52304 | DANA COMMERCIAL VEHICLE PRODUCTS, LLC |
| 81757 | 13125 | CLEVELAND TRENCHER CO INC |
| BT359S | 01212 | FEDERAL-MOGUL CORP GOVERNMENT SALES DEPT |
| D417 | 13125 | CLEVELAND TRENCHER CO INC |
| JD7231 | 92836 | JOHN DEERE TRACTOR WORKS SUB OF DEERE AND CO |
| K359S | F0272 | SKF FRANCE |
| M93561 | 29930 | INTERNATIONAL HARVESTER CO AGRICULTURAL EQUIPMENT DIV |
| M93561 | 31007 | NAVISTAR INTL CORP |
| M93561 | 6N299 | AGCO CORP PARTS OPN |
| PX733 | 89564 | VULCAN-HART CORP |
| ST777 | 29930 | INTERNATIONAL HARVESTER CO AGRICULTURAL EQUIPMENT DIV |
| ST777 | 31007 | NAVISTAR INTL CORP |
| V1116805 | 62265 | VOLVO TRUCKS NORTH AMERICA INC. DBA FOREIGN PARENT IS VOLVO |
| V4338X | 65282 | WHITE MOTOR CORP |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3110-00-142-4358
Related Products | NSN 3110-00-142-4358
Technical Data | NSN 3110-00-142-4358
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| STYLE DESIGNATOR | 552 NORMAL ANGLE |
| BORE DIAMETER | 1.8125 INCHES NOMINAL |
| CONE CORNER RADIUS | 0.0938 INCHES NOMINAL |
| CONE WIDTH | 0.8540 INCHES NOMINAL |
| STANDARD TOLERANCE DESIGNATION | AFBMA CLASS 2 |
Restrictions/Controls & Freight Information | NSN 3110-00-142-4358
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 114820 | BEARINGS/BUSHINGS NOI BALL/ROLLER |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3110-00-142-4358
Air Force
Navy
Marines| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
| Combat Essentiality Code | 5 | Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency. |
| Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
| Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
| Echelon Identification Code | K | Reserved |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DM | U.S. Marine Corps |
| Service Organization | M | U.S. Marine Corps |
| Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
