NSN 3110-00-135-2603 X59001, 205040246003, 205-040-246-003
Product Details | STACK BALL BEARING
3110-00-135-2603 A multiple assembly of more than two bearings matched for duplex mounting. Designed primarily for aircraft propeller and rotary wing aircraft rotor blade applications. See also BEARING, BALL, ANNULAR.
Part Alternates: X59001, 205040246003, 205-040-246-003, 2050402463, 205-040-246-3, 216WI6101, 216WI6-101, 3110-00-135-2603, 00-135-2603, 3110001352603, 001352603
Bearings | Bearings, Antifriction, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 13 JAN 1969 | 00-135-2603 | 30214 ( BEARING, BALL, STACK ) |
Drawings & Photos | NSN 3110-00-135-2603
Demand History | NSN 3110-00-135-2603
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 205-040-246-3 | 2022-03-69 | 2 | DIBBS |
| 205-040-246-3 | 2021-11-332 | 7 | DIBBS |
| 3110-00-135-2603 | 2021-05-125 | 2 | DE |
| 3110-00-135-2603 | 2020-10-304 | 1 | DIBBS-RFPs |
| 205-040-246-3 | 2020-03-85 | 25 | DIBBS |
| 205-040-246-3 | 2019-11-317 | 16 | DIBBS |
| 205-040-246-3 | 2019-07-183 | 16 | DIBBS |
| 205-040-246-3 | 2019-05-136 | 16 | DIBBS |
| 205-040-246-3 | 2019-03-77 | 6 | DIBBS |
| 3110-00-135-2603 | 2018-07-210 | 14 | DIBBS |
| 3110-00-135-2603 | 2018-02-42 | 38 | DIBBS |
| 3110-00-135-2603 | 2017-02-39 | 5 | DIBBS |
| 3110-00-135-2603 | 2016-07-193 | 9 | DIBBS |
| 3110-00-135-2603 | 2016-02-40 | 5 | DIBBS |
| 3110-00-135-2603 | 2015-11-314 | 8 | DIBBS |
| 3110-00-135-2603 | 2015-08-217 | 5 | DIBBS |
| 3110-00-135-2603 | 2015-05-137 | 3 | DIBBS |
| 3110-00-135-2603 | 2015-01-27 | 16 | Hong Kong |
| 3110-00-135-2603 | 2015-01-25 | 3 | DIBBS |
| 3110-00-135-2603 | 2014-10-282 | 3 | DIBBS |
| 3110-00-135-2603 | 2014-02-41 | 21 | DIBBS |
| 3110-00-135-2603 | 2011-08-222 | 25 | DIBBS |
| 3110-00-135-2603 | 2011-07-207 | 4 | DIBBS |
| 3110-00-135-2603 | 2011-03-66 | 4 | DIBBS |
| 3110-00-135-2603 | 2011-01-24 | 3 | DIBBS |
| 3110-00-135-2603 | 2010-05-144 | 8 | DIBBS |
| 3110-00-135-2603 | 2010-03-70 | 13 | DIBBS |
| 205040246003 | 2010-03-60 | 28 | Malaysia |
| 3110-00-135-2603 | 2009-09-259 | 25 | us |
| 3110-00-135-2603 | 2009-08-239 | 25 | Malaysia |
| 2050402463 | 2009-08-225 | 30 | Indonesia |
| 2050402463 | 2009-06-167 | 30 | Malaysia |
Cross Reference | NSN 3110-00-135-2603
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 205-040-246-003 | 97499 | BELL HELICOPTER TEXTRON INC. |
| 205-040-246-3 | 38443 | SKF USA INC DBA SKF AEROENGINE NORTH AMERICA |
| 205-040-246-3 | 97499 | BELL HELICOPTER TEXTRON INC. |
| 216WI6-101 | 21335 | TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE |
| X59001 | 38443 | SKF USA INC DBA SKF AEROENGINE NORTH AMERICA |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3110-00-135-2603
Related Products | NSN 3110-00-135-2603
Technical Data | NSN 3110-00-135-2603
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL BALL STEEL INNER RING STEEL OUTER RING STEEL RETAINER |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 6490 ASSN STD SINGLE MATERIAL RESPONSE BALL AMS 6490 ASSN STD SINGLE MATERIAL RESPONSE INNER RING AMS 6490 ASSN STD SINGLE MATERIAL RESPONSE OUTER RING AMS 6490 ASSN STD SINGLE MATERIAL RESPONSE RETAINER |
| STYLE DESIGNATOR | 224 STACK |
| OVERALL WIDTH | 3.0409 INCHES MINIMUM AND 3.0709 INCHES MAXIMUM |
| BORE DIAMETER | 3.1491 INCHES MINIMUM AND 3.1494 INCHES MAXIMUM |
| OVERALL OUTSIDE DIAMETER | 5.5114 INCHES MINIMUM AND 5.5118 INCHES MAXIMUM |
| STACK ARRANGEMENT | 2 BEARINGS TANDEM,1 BEARING REVERSED |
| SPECIAL FEATURES | 4 SLOTS 90 DEG APART ON BOTH SIDES OF OUTER RING,INNER AND OUTER RINGS BLACK OXIDE COATED |
| TEST DATA DOCUMENT | 21335-APS-33 SPECIFICATION AND 21335-APS-3A6 SPECIFICATION AND 38443-AQCP-2A SPECIFICATION AND 38443-AQCP-9A SPECIFICATION |
| III PRECIOUS MATERIAL | SILVER |
| III PRECIOUS MATERIAL AND LOCATION | RETAINER SILVER |
| MANUFACTURERS CODE | 97499 |
| MFR SOURCE CONTROLLING REFERENCE | 205-040-246-3 |
Restrictions/Controls & Freight Information | NSN 3110-00-135-2603
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | S | Item contains silver |
| Criticality Code: | F | The item is an Aviation Critical Safety Item/Flight Safety Critical Aircraft Part ((ACSI/FSCAP). |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 114820 | BEARINGS/BUSHINGS NOI BALL/ROLLER |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | CT | U.S. Army Aviation and Missile Command (AIR) Redstone Arsenal, AL 35898-5230 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3110-00-135-2603
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | T | Industrial Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | AH | (Non-JSL Items)HELICOPTERS(H1) |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
