NSN 3010-00-972-8404 1115PC259, 553037, 592194
Product Details | CLUTCH DISK
3010-00-972-8404 A solid circular disk of wire-woven lining material or ceramic and metal substance and the like, molded to one or both sides and fastened directly or indirectly to the center spline or hub, which receives and transmits motion or power by engagement with the pressure plate assembly and the flywheel or the like. Includes dry or wet type disk, and may include damper springs. This item is designed to be used on marine, aircraft, and plant equipment in conjunction with a CLUTCH ASSEMBLY, FRICTION.
Part Alternates: 1115PC259, 553037, 592194, 3010-00-972-8404, 00-972-8404, 3010009728404, 009728404
Mechanical Power Transmission Equipment | Torque Converters and Speed Changers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 30 | 01 JAN 1962 | 00-972-8404 | 52059 ( DISK, CLUTCH, NONVEHICULAR ) |
Cross Reference | NSN 3010-00-972-8404
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1115PC259 | 1UVT5 | BRP US INC. |
| 1115PC259 | 21119 | EVINRUDE MOTORS PRODUCT GROUP OF OUTBOARD MARINE |
| 1115PC259 | 32195 | OUTBOARD MARINE CORP JOHNSON MOTORS DIV |
| 1115PC259 | 80256 | OUTBOARD MARINE CORP |
| 553037 | 80256 | OUTBOARD MARINE CORP |
| 592194 | 1UVT5 | BRP US INC. |
| 592194 | 21119 | EVINRUDE MOTORS PRODUCT GROUP OF OUTBOARD MARINE |
| 592194 | 26840 | HALE PRODUCTS INC. |
| 592194 | 32195 | OUTBOARD MARINE CORP JOHNSON MOTORS DIV |
| 592194 | 80256 | OUTBOARD MARINE CORP |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3010-00-972-8404
Related Products | NSN 3010-00-972-8404
Technical Data | NSN 3010-00-972-8404
| Characteristic | Specifications |
|---|---|
| DISK MATERIAL | STEEL |
| DESIGN TYPE | DRY |
| FLEXIBILITY | RIGID |
| DISK TYPE | PLAIN |
| CONSTRUCTION | SOLID |
| OUTSIDE DIAMETER | 3.000 INCHES NOMINAL |
| SPLINE TYPE | STRAIGHT |
| SPLINE QUANTITY | 6 |
| SPLINE MAJOR DIAMETER | 0.500 INCHES NOMINAL |
| FEATURES PROVIDED | FRICTION MATERIAL FACING AND MATERIAL FACING GROOVE |
| SPECIAL FEATURES | INTEGRAL HUB INCLUDED |
| (NON-CORE DATA) INSIDE DIAMETER | 1.750 INCHES NOMINAL |
| (NON-CORE DATA) SPLINE MINOR DIAMETER | 0.406 INCHES NOMINAL |
| (NON-CORE DATA) OVERALL LENGTH | 1.094 INCHES NOMINAL |
| (NON-CORE DATA) THICKNESS | 0.125 INCHES NOMINAL |
| (NON-CORE DATA) MATERIAL THICKNESS | 0.125 INCHES NOMINAL |
| (NON-CORE DATA) MATERIAL LOCATION | ONE SIDE |
| (NON-CORE DATA) DESIGN FORM | SOLID |
| (NON-CORE DATA) ASBESTOS COMPOSITION TYPE | MOLDED |
| (NON-CORE DATA) MATERIAL OUTSIDE DIAMETER | 3.000 INCHES NOMINAL |
| (NON-CORE DATA) MATERIAL INSIDE DIAMETER | 2.094 INCHES NOMINAL |
| (NON-CORE DATA) FACING ATTACHMENT METHOD | RIVETED |
| (NON-CORE DATA) DISTANCE FROM FLYWHEEL FACE TO REAR OF HUB | 1.000 INCHES NOMINAL |
| (NON-CORE DATA) MATERIAL | ASBESTOS |
Restrictions/Controls & Freight Information | NSN 3010-00-972-8404
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 126840 | POWER TRANS BELT CLAMPS,GUIDES ETC |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 590 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3010-00-972-8404
Army
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 AY : Assembly |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 AY : Assembly |
