NSN 2925-00-878-1136 2040602001, 204-060-200-1, 00-878-1136
Product Details | AIRCRAFT ENGINE STARTER-GENERATOR
2925-00-878-1136 A rotating machine which is an accessory to and directly cranks an aircraft engine and subsequently generates direct current. The generator and starter action is not simultaneous. See also STARTER,ENGINE,ELECTRICAL and GENERATOR,ENGINE ACCESSORY. Excludes STARTER-GENERATOR,ENGINE,AIR TURBINE DRIVEN.
Part Alternates: 2040602001, 204-060-200-1, 2925-00-878-1136, 00-878-1136, 2925008781136, 008781136
Engine Accessories | Engine Electrical System Components, Aircraft Prime Moving
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 29 | 30 AUG 1967 | 00-878-1136 | 51414 ( STARTER-GENERATOR, ENGINE, AIRCRAFT ) |
Drawings & Photos | NSN 2925-00-878-1136
Demand History | NSN 2925-00-878-1136
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2925-00-878-1136 | 2022-02-41 | 1 | CL |
| 2925-00-878-1136 | 2020-04-106 | 1 | US |
| 2040602001 | 2020-02-59 | 1 | BR |
| 2925-00-878-1136 | 2020-02-59 | 1 | BR |
| 2925-00-878-1136 | 2019-06-158 | 1 | US |
| 2040602001 | 2019-01-15 | 2 | South Korea |
| 2040602001 | 2018-04-106 | 3 | UY |
| 204-060-200-1 | 2017-02-33 | 1 | Philippines |
| 2925-00-878-1136 | 2016-06-181 | 1 | Philippines |
| 2040602001 | 2014-04-106 | 3 | United States |
| 2925-00-878-1136 | 2013-10-294 | 2 | United States |
| 2040602001 | 2012-12-352 | 1 | TR |
| 204-060-200-1 | 2012-08-223 | 2 | United States |
| 2925-00-878-1136 | 2011-03-83 | 10 | US |
| 2925-00-878-1136 | 2010-04-98 | 1 | US |
| 2925-00-878-1136 | 2010-04-96 | 1 | United States |
| 2040602001 | 2009-05-134 | 1 | Chile |
| 2925-00-878-1136 | 2009-02-44 | 1 | Chile |
| 2925-00-878-1136 | 2008-08-225 | 1 | Brazil |
Cross Reference | NSN 2925-00-878-1136
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 204-060-200-1 | 97499 | BELL HELICOPTER TEXTRON INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2925-00-878-1136
Related Products | NSN 2925-00-878-1136
Technical Data | NSN 2925-00-878-1136
| Characteristic | Specifications |
|---|---|
| VOLTAGE IN VOLTS | 30.0 |
| MAXIMUM OUTPUT CURRENT RATING IN AMPS | 300.0 |
| GROUNDING METHOD | EXTERNAL |
| SHAFT ROTATION DIRECTION | COUNTERCLOCKWISE |
| MOUNTING STYLE | 5 ROUND FLANGE W/SLOTS EVENLY SPACED |
| SLOT WIDTH | 0.400 INCHES MINIMUM AND 0.430 INCHES MAXIMUM |
| SLOT LENGTH | 1.1985 INCHES MINIMUM AND 1.2255 INCHES MAXIMUM |
| MOUNTING HOLE CIRCLE RADIUS | 2.500 INCHES NOMINAL |
| SLOT QUANTITY | 6 |
| SHAFT DRIVE END STYLE | 4 SPLINED SHAFT END |
| SPLINE MINOR DIAMETER | 0.727 INCHES MAXIMUM |
| SPLINE MAJOR DIAMETER | 0.862 INCHES MINIMUM AND 0.867 INCHES MAXIMUM |
| SPLINE WIDTH | 0.070 INCHES MINIMUM AND 0.073 INCHES MAXIMUM |
| SPLINE LENGTH | 0.600 INCHES MINIMUM |
| SPLINE QUANTITY | 16 |
| SUBMERSIBILITY | NONSUBMERSIBLE |
| MAXIMUM OPERATING ALTITUDE RATING | NOT RATED |
| ENVIRONMENTAL PROTECTION | FUNGUS RESISTANT |
| FURNISHED ITEMS | RADIO INTERFERENCE SHIELDING |
Restrictions/Controls & Freight Information | NSN 2925-00-878-1136
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
| Less than car load rating | D | 200 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 738 | unknown |
| Originating Activity Code | CT | U.S. Army Aviation and Missile Command (AIR) Redstone Arsenal, AL 35898-5230 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2925-00-878-1136
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | H | Aircraft, Air Materiel |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 1 | REPARABLE ITEMS (Exclusive of Insurance and Provisioning Items.) This code will be used to identify serviceable or unserviceable items of a durable nature which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance. |
| Specific Group/Generic Code | C | Other Aircraft Categories |
| Weapons Systems/End Item or Homogeneous Group | CF | Flexible Engine Diagnostic System (FEDS). |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | B17 | US Army Aviation and Missile Command (Air) ATTN: AMSMI-LC-MM-C Redstone Arsenal, AL 35898-5230 |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | D | When repair is beyond lower level maintenance capability, evacuate the item to depot. Disposal is not authorized below wholesale level. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | GA | TG:H-1 IROQUOIS |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | B17 | US Army Aviation and Missile Command (Air) ATTN: AMSMI-LC-MM-C Redstone Arsenal, AL 35898-5230 |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | P | Stock Fund (except Munitions) |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9W | Navy-owned stocks of material managed by the Army within the Army Troop Support and Aviation Materiel Readiness Command Naval Inventory Control Point, Mechanicsburg |
| Issue Repair, or Requisition | R9 | Integrated Manager reparable item. Includes Defense Logistics Agency-managed items which are reportable in non-RFI condition to appropriate Defense Supply Center per NAVSUP instructions for return of excess material to DLA. |
| Source of Supply | B17 | US Army Aviation and Missile Command (Air) ATTN: AMSMI-LC-MM-C Redstone Arsenal, AL 35898-5230 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
