NSN 2840-01-322-4748 1522M52P08, 01-322-4748, 013224748
Product Details | AIRCRAFT GAS TURBINE ENGINE TURBINE SHROUD SEGMENT
2840-01-322-4748 A stationary arched metal segment used to establish clearance and a seal for the tip of a BLADE, TURBINE ROTOR, AIRCRAFT GAS TURBINE ENGINE. The inner dimension may have open honeycomb or composition filled surface or may be formed by the knife edge metal protrusions of a SEAL RING, LABYRINTH, AIRCRAFT GAS TURBINE ENGINE.
Part Alternates: 1522M52P08, 2840-01-322-4748, 01-322-4748, 2840013224748, 013224748
Engines, Turbines, and Components | Gas Turbines and Jet Engines, Aircraft, Prime Moving; and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 28 | 07 JUL 1990 | 01-322-4748 | 50603 ( SHROUD SEGMENT, TURBINE, AIRCRAFT GAS TURBINE ENGINE ) |
Cross Reference | NSN 2840-01-322-4748
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1522M52P08 | 07482 | GENERAL ELECTRIC COMPANY DBA GE |
| 1522M52P08 | 08244 | MOELLER MFG. COMPANY, INC. DIV AIRCRAFT |
| 1522M52P08 | 0W483 | T. Q. MACHINING INC. |
| 1522M52P08 | 13779 | LPI INDUSTRIES CORPORATION DBA L P I |
| 1522M52P08 | 26199 | JOHNSON TECHNOLOGY, INC. |
| 1522M52P08 | 33617 | ELECTRO-METHODS INC |
| 1522M52P08 | 3V257 | HOWMET CORPORATION DIV HOWMET MACHINING |
| 1522M52P08 | 96965 | TURBINE AIRFOIL DESIGNS INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2840-01-322-4748
Related Products | NSN 2840-01-322-4748
Technical Data | NSN 2840-01-322-4748
| Characteristic | Specifications |
|---|---|
| ENGINE SECTION LOCATION | HIGH PRESSURE TURBINE |
| CRITICALITY CODE JUSTIFICATION | AGAV |
| III END ITEM IDENTIFICATION | ACFT ENG F110GE100 |
| MANUFACTURERS CODE | 07482 |
| DESIGN CONTROL REFERENCE | 1522M52P08 |
Restrictions/Controls & Freight Information | NSN 2840-01-322-4748
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 011790 | AIRCRAFT PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 671 | unknown |
| Originating Activity Code | SX | Oklahoma City Air Logistics Center Tinker AFB, OK 73145-3043 |
| Air Dimension Code | Z | Shipment is not a consolidation, but does exceed 72 inches in one or more dimensions. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2840-01-322-4748
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | P | The current standard price is the initial negotiated provisioned price.
|
| Materiel Management Aggregation Code | PR | SX:F11O GE 100 ENGINE |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
