Product Details | AIRCRAFT GAS TURBINE ENGINE HEAT SHIELD
2840-01-201-1649 A rigid item, fabricated from a heat resistant allow, with or without insulation material added. Designed to protect parts, areas or systems of an ENGINE, GAS TURBINE, AIRCRAFT from excessive heat damage. See also INSULATION BLANKET, THERMAL, AIRCRAFT GAS TURBINE ENGINE.
Part Alternates: 9529M86P05, 2840-01-201-1649, 01-201-1649, 2840012011649, 012011649
Engines, Turbines, and Components | Gas Turbines and Jet Engines, Aircraft, Prime Moving; and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 28 | 13 FEB 1985 | 01-201-1649 | 50356 ( SHIELD, HEAT, AIRCRAFT GAS TURBINE ENGINE ) |
