NSN 2815-00-218-6912 126021BS, 00-218-6912, 002186912
Product Details | ENGINE POPPET VALVE PUSH ROD
2815-00-218-6912 A tubular or solid item specifically designed to transmit intermittent motion from the engine poppet valve tappet to the engine poppet valve rocker arm.20328050063Gasoline Reciprocating Engines, Except Aircraft; and Components28100068Gasoline Reciprocating Engines, Aircraft Prime Mover; and Components28150029Diesel Engines and Components
Part Alternates: 126021BS, 2815-00-218-6912, 00-218-6912, 2815002186912, 002186912
Engines, Turbines, and Components | Diesel Engines and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 28 | 01 JAN 1963 | 00-218-6912 | 22102 ( PUSH ROD, ENGINE POPPET VALVE ) |
Drawings & Photos | NSN 2815-00-218-6912
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 2815-00-218-6912
Technical Data | NSN 2815-00-218-6912
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL |
| END HARDNESS RATING | 57.0 ROCKWELL C MINIMUM AND 63.0 ROCKWELL C MAXIMUM |
| END CASEHARDENING INDICATOR | CASEHARDENED |
| BODY OUTSIDE DIAMETER | 0.438 INCHES NOMINAL |
| OVERALL LENGTH | 12.078 INCHES NOMINAL |
| STYLE DESIGNATOR | K11 CUP FIRST END |
| CHAMFER ANGLE IN DEG | 30.0 SECOND END |
| SHOULDER LENGTH | 0.031 INCHES NOMINAL SECOND END |
| CHAMFER LENGTH | 0.094 INCHES NOMINAL SECOND END |
| FIRST STEP DIAMETER | 0.438 INCHES NOMINAL SECOND END |
| FIRST STEP LENGTH | 0.063 INCHES NOMINAL SECOND END |
| END LENGTH | 0.188 INCHES NOMINAL SECOND END |
| END LARGEST DIAMETER | 0.625 INCHES NOMINAL FIRST END 0.483 INCHES NOMINAL SECOND END |
| FLAT DIAMETER | 0.125 INCHES NOMINAL SECOND END |
| END SPHERICAL RADIUS | 0.223 INCHES MINIMUM FIRST END 0.225 INCHES MAXIMUM FIRST END |
| SPHERICAL RADIUS DEPTH | 0.219 INCHES NOMINAL FIRST END |
| BODY TYPE | TUBULAR |
| SPECIAL FEATURES | PAC STYL 2ND END PER SKETCH |
| III FSC APPLICATION DATA | ENGINE,DIESEL |
| MANUFACTURERS CODE | 1ML14 |
| DESIGN CONTROL REFERENCE | 126021BS |
Restrictions/Controls & Freight Information | NSN 2815-00-218-6912
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 120800 | ENGINES, INTERNAL COMBUSTION, NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2815-00-218-6912
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
