Product Details | MASTER HYDRAULIC BRAKE CYLINDER ASSEMBLY

2530-00-978-2068 A device consisting of a reservoir and/or CYLINDER, HYDRAULIC BRAKE, MASTER with other components necessary to displace fluid from a central source for actuating the slave or wheel cylinders of a hydraulic brake system.20216300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components

Part Alternates: 10916089, 25309782068, 2530-00-978-2068, 00-978-2068, 2530009782068, 009782068

Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
25	01 JAN 1962	00-978-2068	11007 ( CYLINDER ASSEMBLY, HYDRAULIC BRAKE, MASTER )
