Product Details | MASTER HYDRAULIC BRAKE CYLINDER ASSEMBLY

2530-00-272-7966 A device consisting of a reservoir and/or CYLINDER, HYDRAULIC BRAKE, MASTER with other components necessary to displace fluid from a central source for actuating the slave or wheel cylinders of a hydraulic brake system.20216300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components

Part Alternates: M6086, MC6086, E6086, F6086, FC6086, FE1444, FE1446, GP2140, J99999178, 0006051173, 000605-1173, 1063, 10A3724, 115964, 1395, 15708, 174290, 174-290, 2983, 3106509, 3116919, 3126544, 5472938, 6086, 637423, 8376260, 860203, A556, 2530-00-272-7966, 00-272-7966, 2530002727966, 002727966

Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components

Supply Group (FSG) NSN Assign. NIIN
25 01 JAN 1963 00-272-7966

Drawings & Photos | NSN 2530-00-272-7966


Demand History | NSN 2530-00-272-7966

Part Number Request Date QTY Origin
2530-00-272-7966 2022-12-339 10 UM
2530-00-272-7966 2015-01-29 60 DIBBS
2530-00-272-7966 2014-06-154 60 DIBBS
2530-00-272-7966 2013-03-73 50 DIBBS
2530-00-272-7966 2012-03-85 30 DIBBS
E6086 2012-02-55 1 US
2530-00-272-7966 2010-01-29 120 DIBBS
2530-00-272-7966 2009-12-337 50 DIBBS
2530-00-272-7966 2009-10-297 50 DIBBS
2530-00-272-7966 2008-03-76 54 DIBBS
2530-00-272-7966 2007-06-166 15 DIBBS

Cross Reference | NSN 2530-00-272-7966

Part Number Cage Code Manufacturer
000605-1173 16662 LIFT PARTS MFG CO INC DIV OF ECHLIN MFG CO THE
000605-1173 66654 TVH PARTS CO.
1063 06840 BENDIX CORP THE
10A3724 81240 WHITE FARM EQUIPMENT CO SUB OF TIC INVESTMENT INC
115964 34623 AM GENERAL, LLC
1395 14894 ALLIED AUTOMOTIVE ALLIED AFTERMARKET DIV
15708 78640 MITSUBISHI CATERPILLAR FORKLIFT AMERICA INC
174-290 16758 GENERAL MOTORS CORP DELCO ELECTRONICS DIV
174-290 76462 DELCO MORAINE DIV OF GENERAL MOTORS CORP
2983 41340 MONTGOMERY WARD AND CO INC
3106509 99343 CHRYSLER CORP ENGINE AND COMPONENTS SALES
3116919 99343 CHRYSLER CORP ENGINE AND COMPONENTS SALES
3126544 99343 CHRYSLER CORP ENGINE AND COMPONENTS SALES
5472938 23862 MILITARY VEHICLES OPN GENERAL MOTORS TRUCK AND BUS GROUP
5472938 7X677 GENERAL MOTORS LLC DBA GENERAL MOTORS
6086 19239 ECHLIN INC
637423 34623 AM GENERAL, LLC
8376260 19207 U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM
860203 12603 CLARK EQUIPMENT CO
860203 77237 DANA OFF HIGHWAY PRODUCTS, LLC
A556 99343 CHRYSLER CORP ENGINE AND COMPONENTS SALES
E6086 80724 EIS BRAKE PARTS DIV OF STANDARD MOTOR PRODUCTS INC
F6086 63477 FEDERAL MOGUL CORP SUB WAGNER BRAKE
FC6086 12603 CLARK EQUIPMENT CO
FC6086 63477 FEDERAL MOGUL CORP SUB WAGNER BRAKE
FE1444 63477 FEDERAL MOGUL CORP SUB WAGNER BRAKE
FE1446 63477 FEDERAL MOGUL CORP SUB WAGNER BRAKE
GP2140 23040 FORD MOTOR CO FORD PARTS AND SERVICE DIV
GP2140 57526 FORD MOTOR CO
J99999178 99343 CHRYSLER CORP ENGINE AND COMPONENTS SALES
M6086 71425 AIRTEX PRODUCTS DIV OF UIS INC
MC6086 34558 BRAKE PARTS CO SUB OF THE ECHLIN MFG CO
MC6086 66614 TRW INC REPLACEMENT PARTS DIV
MC6086 76761 C. E. NIEHOFF & CO.

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 2530-00-272-7966

Technical Data | NSN 2530-00-272-7966

Characteristic Specifications
OVERALL WIDTH 2.250 INCHES NOMINAL
OVERALL HEIGHT 4.250 INCHES NOMINAL
EXTENDED LENGTH 7.188 INCHES NOMINAL
COMPRESSED LENGTH 6.062 INCHES NOMINAL
BODY MATERIAL ANY ACCEPTABLE
BORE DIAMETER 1.000 INCHES NOMINAL
FIRST PISTON ROD END THREAD SERIES DESIGNATOR UNF
FIRST PISTON ROD END THREAD DIAMETER 0.438 INCHES NOMINAL
FIRST PISTON ROD END THREAD QUANTITY PER INCH 20
FIRST PISTON ROD END THREAD CLASS 2B
FIRST PISTON ROD END THREAD DIRECTION RIGHT-HAND
(NON-CORE DATA) FIRST PISTON ROD END LUBRICATION FACILITY NOT INCLUDED
MOUNTING TYPE AND LOCATION BOSS CENTER SECTION
MOUNTING PROVISION THREADED MOUNTING HOLES AND UNTHREADED MOUNTING HOLES
MOUNTING FACILITY THREAD SERIES DESIGNATOR UNC
MOUNTING FACILITY THREAD DIAMETER 0.312 INCHES NOMINAL
MOUNTING FACILITY THREAD QUANTITY PER INCH 18
MOUNTING FACILITY THREAD CLASS 2B
MOUNTING FACILITY THREAD DIRECTION RIGHT-HAND
MOUNTING FACILITY THREAD LENGTH 0.562 INCHES NOMINAL
MOUNTING FACILITY DIAMETER 0.328 INCHES NOMINAL
PORT LOCATION AND QUANTITY 2 CYLINDER HEAD END
PORT STYLE 7 INVERTED FLARE
PORT THREAD SERIES DESIGNATOR UNF
PORT THREAD DIAMETER 0.375 INCHES NOMINAL
PORT THREAD QUANTITY PER INCH 24
PORT THREAD CLASS 2B
SEAT ANGLE IN DEG 45.0
TEMP RATING NOT RATED
RESERVOIR TYPE INTEGRAL
ACTUATION METHOD DIRECT
STOPLIGHT SWITCH THREAD SERIES DESIGNATOR NPT
STOPLIGHT SWITCH NOMINAL PIPE THREAD SIZE 0.125 INCHES
FEATURES PROVIDED CUSHIONED STROKE

Restrictions/Controls & Freight Information | NSN 2530-00-272-7966

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 018400 AUTO BRAKES/SHOES R PADS ETC
Less than car load rating
Less than truck load rating Q 70.0
Water commodity Code 581 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 2530-00-272-7966

Category Code Description
Materiel Category and Inventory ManagerJ Ground Forces Support Materiel (DLA/GSA Items)
Appropriation and Budget Activity2 Stock Fund Secondary Items
Management Inventory Segment2 NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code0 Medical Materiel
Weapons Systems/End Item or Homogeneous Group00DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements CodeX Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDADepartment of the Army
Service OrganizationAU.S. Army
ReparabilityZThis is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
Category Code Description
Budget Code9 General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund CodeSFStock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDFDepartment of the Air Force
Service OrganizationFU.S. Air Force
ReparabilityNStock Fund (except Munitions)
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
